GE GSE26HSESS Dimensions And Installation Information

GSE26HSE
GE ENERGY STAR
® ®
Dimensions and Installation Information (in inches)
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90˚ (in.) F
Width (in.) G
Width with door open 90˚ inc. door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
† Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
25.9 Cu. Ft. Side-By-Side Refrigerator with Dispenser
69-1/2
69
28
32-1/4
34-3/4
50
35-3/4
43-1/2
1/8
1
2
For answers to your Monogram
questions, visit our website at geappliances.com or
call GE Answer Center service, 800.626.2000.
®
A B
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90˚ (in.) F
Width (in.) G
Width with door open 90˚ inc. door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
or GE appliance
®
H
G
C
D
69-1/2
69
28
32-1/4
34-3/4
50
35-3/4
43-1/2
1/8
1
Listed by
2
Underwriters
Laboratories
Specification Revised 9/13
E
F
As an EnErgy StAr ®
partner, gE has determined
that this product meets the
EnErgy StAr guidelines
for energy efficiency.
310153
