GE Profile PB930SFSS Dimensions And Installation Information

PB930SF
GE Profile Series 30" Free-Standing Electric Convection Range
™
Dimensions and Installation Information (in inches)
Receptacle Locations
Locally approved flexible service cord or conduit must be used
because terminals are not accessible after range installation.
See shaded area in drawing for location of electrical outlet box.
Recommended outlet locations allow range to be installed directly
against wall.
Note: This appliance has been approved for 0" spacing to
adjacent surfaces above the cooktop. However, a 6" minimum
spacing to surfaces less than 15" above the cooktop and
adjacent cabinet is recommended to reduce exposure to
steam, grease splatter and heat.
Installation Information: Before installing, consult installation
instructions for current dimensional data and additional
requirements.
KW Rating
240V
13.5
208V 10.1
Breaker Size
240V 40 Amps †
208V 40 Amps
†
Note: Check local codes for required breaker size.
†
For answers to your Monogram or GE
®
appliance questions, visit our website at
geappliances.com or call GE Answer Center
service, 800.626.2000.
with Warming Drawer
Acceptable electrical
outlet area
29-7/8
®
®
30
2-1/2
25
7
14-1/2
11
47
35-3/4
to
On models with warming drawers,
36-1/2
electrical outlet must not
be in this area.
25-1/2
w/o handle
28
w/handle
47-7/8
All GE ranges are equipped with
Listed by
an Anti-Tip device. The installation
Underwriters
of this device is an important,
required step in the installation Laboratories
of the range.
Specification Created 5/13
2-1/2
7-1/2
221042
