Dell Inspiron 1120 Troubleshooting Manual

Contents: mini pci type 3b data fax modem by 3com user's guide.
Hide thumbs
Mini PCI Type 3B Data Fax Modem By 3Com User's Guide

Introduction
Installation
Using the modem
Command Set
S-Registers
Result Codes
Troubleshooting
Specifications
Regulatory
Information in this document is subject to change without notice.
© 1999 3Com. All rights reserved.
Trademarks used in this text: 3Com are registered trademarks of 3Com; Dell and the DELL logo are trademarks of Dell Computer Corporation; Adobe is a trademark of Adobe
Systems Incorporated, which may be registered in certain jurisdictions; Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. 3Com disclaims any
proprietary interest in trademarks and trade names other than its own.
Initial release: 6 Nov 1999



Advertising

   Also See for Dell Inspiron 1120

   Related Manuals for Dell Inspiron 1120

   Summary of Contents for Dell Inspiron 1120

  • Page 1

    © 1999 3Com. All rights reserved. Trademarks used in this text: 3Com are registered trademarks of 3Com; Dell and the DELL logo are trademarks of Dell Computer Corporation; Adobe is a trademark of Adobe Systems Incorporated, which may be registered in certain jurisdictions; Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.

  • Page 2

    Back to Contents Page Modem AT Commands: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide  Modem AT Commands    CAUTION: In most cases, your modem will work using the factory-set defaults. We recommend that you have a good understanding of modems before you change any settings.

  • Page 3

    ATDL? Display last dialed number   ATDSn Dial stored number   ATE0 Turn command echo off   ATE1 Turn command echo on ATF0 Turn online echo on   ATF1 Turn online echo off ATH0 Hang up (go on-hook)   ATH1 Pick up (go off-hook)  ...

  • Page 4

      rate i.e., OK, CONNECT, RING, NO CARRIER, NO ANSWER, CONNECT XXXX, BUSY and ERROR ATX4 Report all call progress result codes and connection rate i.e., OK, CONNECT, RING, NO CARRIER, NO ANSWER, CONNECT XXXX, BUSY, NO DIAL TONE and ERROR ATY0 On the next reset, use &W settings ATY1...

  • Page 5

    &H3 AT&H3 Flow control for transmitted data - Enable both software   and hardware flow control &I0 AT&I0 Flow control for received data - Disable flow control &I1 AT&I1 Flow control for received data - send XON/XOFF signals   to modems on both ends &I2 AT&I2 Flow control for received data - send XON/XOFF signals...

  • Page 6

    &N24 AT&N24 Link Speed - 48000 bps   &N25 AT&N25 Link Speed - 49333 bps   &N26 AT&N26 Link Speed - 50666 bps   &N27 AT&N27 Link Speed - 52000 bps   &N28 AT&N28 Link Speed - 53333 bps   &N29 AT&N29 Link Speed - 54666 bps...

  • Page 7

    &U29 AT&U29 Minimum link rate-54666 bps   &U30 AT&U30 Minimum link rate-56000 bps   &U31 AT&U31 Minimum link rate-57333 bps   &W0 AT&W0 Write (store) user profile 0 to memory   &W1 AT&W1 Write (store) user profile 1 to memory  ...

  • Page 8

    Back to Contents Page Installation: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide Overview • Connecting the Cable • Configuring Communications Software  Overview Congratulations on your choice of a Mini PCI Type 3B Data Fax Modem by 3Com. Now 3Com’s superior modem technology is built in to your computer, allowing you to transfer data and faxes faster than ever.

  • Page 9

    Back to Contents Page Introduction: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide Overview • Features  Overview Model Name:    Mini PCI type 3B Data Fax Modem by 3Com Model Number:   3CN3BM556-D-100 Your Mini PCI 56K (V.90) modem by 3Com can connect at speeds up to 56,000 bits per second (bps), although FCC regulations currently limit download speeds to 53,333 bps.

  • Page 10

    Back to Contents Page Modem S-Registers: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide  Modem S-Registers The AT command settings are stored in the S-Registers. S-Register values can be changed either by entering an AT command or by entering the new value of the S-Register, preceded by AT, like this:  ...

  • Page 11

    hangup; if S1=255, the modem will not hang up when the carrier is lost; dropping DTR hangs up the modem (1/10 second)         Duration of the touchtone dialing tone 50-255 70 ms spacing         Guard time for the escape code (1/50 0-255 second)

  • Page 12

            DTR debounce time indicator (1/100 0-255 second)         Bitmapped register. 1 = V.21 mode         2 = Disable TCM     4 = Disable V.32       8 = Disable 21Hz  ...

  • Page 13

            Delay before forced hangup (optional) 0-255 Back to Contents Page...

  • Page 14

    Back to Contents Page Regulatory: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide Manufacturer Declaration of Conformity • FCC Part 15 Class B Verification Statement • Industry Canada (IC) Emissions Compliance Statement •  VCCI Statement • FCC Part 68 Statement • Industry Canada (IC) Notice • CE Compliance  Manufacturer’s U.S.

  • Page 15

     U.S. FCC Part 68 Statement The modem complies with Part 68 of the Federal Communications Commission (FCC) rules. On the computer is a label that contains the FCC registration number and Ringer Equivalence Number (REN) for this device. If requested, this information must be provided to the telephone company.

  • Page 16

    amended by 93/68/EEC and the Telecom Terminal Equipment and Satellite Earth Stations Directive 98/13/EC. Such marking is indicative that this equipment meets or exceeds the following technical standards: EN 55022 - Limits and Methods of Measurement of Radio Interference Characteristics of Information Technology Equipment. (CISPR 22 Class B).

  • Page 17: Modem Result Codes

    Back to Contents Page Modem Result Codes: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide  Modem Result Codes Result codes are messages that appear on your computer screen to inform you of the status of modem actions or when an error has occurred. The result codes that can appear depend on the setting of the ATXn command (see ATXn in the AT Commands list).

  • Page 18

    CONNECT 46666   CONNECT 48000   CONNECT 49333   CONNECT 50666   CONNECT 52000   CONNECT 53333   CONNECT 54666   CONNECT 56000   CONNECT 57333   The following functions are also available: Adaptive dialing Wait for 2nd Dial Tone (W)  ...

  • Page 19

    Back to Contents Page Specifications: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide General • Operational • Mechanical • Electrical • Environmental • Protocols and Standards  General Manufacturer 3Com Corporation Model 3CN3BM556-D-100 Chipset 3Com/ADI 1826 - Controllerless Fax/Modem Countries Supported United States Canada  Operational Asynchronous Character Format...

  • Page 20

    Operating Environment Altitude: Operating-up to 10,000 ft. (3050m) Non-operating-up to 30,000 ft (9100m) Humidity: Operating-10% to 90% noncondensing Non-operating-5% to 95% @ 39 C  Protocols and Standards Dialing Capability Tone Fax Capability ITU-T V.17 ITU-T V.29 ITU-T V.27ter ITU-T V.21 channel 2 Group 3 fax, class 1 Line Requirements RJ11...

  • Page 21

    Back to Contents Page Troubleshooting: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide Common Problems and Solutions • How to Properly Uninstall Modem Drivers  Common Problems and Solutions    Message/Symptom Possible Solution ERROR If you are typing from the command line in terminal mode, try retyping the command.  Make sure that you issued the correct AT command.  Modem Communication Error or If fax software is being used, make sure the correct fax class (Class 1) is selected. ...

  • Page 22

    Modem does not respond or This is usually due to incorrect driver installation. If the driver installation is unsuccessful uninstall and "Port Not Available" message repeat the driver installation. appears 1. To remove the driver click Settings>Control Panel>System>Device Manager>Modem 2. Select the 3Com Modem and click Remove. 3.

  • Page 23

    Back to Contents Page Using the modem: Mini PCI Type 3B Data Fax Modem by 3Com User's Guide Overview • Transferring Data • Faxing  Overview Your modem allows you to send and receive both data and fax files using your communications software. Your modem can also be used for data communications with an online service, the Internet, an electronic Bulletin Board System (BBS), or another modem, at up to V.90 speeds.

  • Page 24

    To manually dial another modem, go into terminal mode in your communications software, and enter ATDT followed by a space and the telephone number. When dialing, enter the same information you would if you were calling someone on the phone. For example, when dialing long distance, prefix the phone number with a 1 and the area code.

  • Page 25

    Avoid loading more than one fax package at a time on your computer. Because all fax software packages use the same types of files for operation, conflicts frequently occur if you have more than one fax program installed. Because many fax drivers keep possession of the COM port after being loaded, you may need to unload the fax driver in order to use other modem functions.
