Hotpoint HTWP1400FWW Dimension Manual

3.5 doe cu. ft. capacity washer

Hide thumbs Also See for HTWP1400FWW:

Download this manual See also: Use and Care Manual

HTWP1400F– Hotpoint

Washer Dimensions (in inches)

25-1/2

Side View

Specification Created 2/13

460157

23-1/2

25-3/4

3.5 DOE cu. ft. capacity washer

Rear View

*24-1/2" from the edge of the side panel to the front.

25-1/2" from front to edge of endcaps.

Circuit Requirements: An individual, properly-grounded branch circuit,

with a three-prong grounding-type receptacle, protected by a 15 or

20 amp circuit breaker or a time-delay fuse, is required.

Electrical Rating: 115V, 60Hz, 10 Amps

Installation Information: Before installing, consult installation

instructions packed with product for current dimensional data.

Washer Note: Washer wall outlet must be located within 36" of

service cord entry. Wall outlet must not be located behind dryer.

Listed by

Underwriters

Laboratories

Page 1: Rear View
HTWP1400F– Hotpoint 3.5 DOE cu. ft. capacity washer ® Washer Dimensions (in inches) Circuit Requirements: An individual, properly-grounded branch circuit, 25-1/2 with a three-prong grounding-type receptacle, protected by a 15 or 20 amp circuit breaker or a time-delay fuse, is required.
Page 2 • 4 water levels - Select water level based on load size • 8 wash cycles - Handle various fabrics and soils • 3 wash/rinse temperatures - A variety of temperatures provide great wash results • Model HTWP1400FWW – White HTWP1400FWW Specification Created 2/13...
