HTWP1200D– Hotpoint
Washer Dimensions (in inches)
25-1/2
36
Side View
Specification Created 1/12
460155
23-1/2
25-3/4
3.5 DOE cu. ft. capacity ExtrAction
®
27
51
42
Rear View
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
ribbed basket
™
Circuit Requirements: An individual, properly-grounded branch circuit,
with a three-prong grounding-type receptacle, protected by a 15 or
20 amp circuit breaker or a time-delay fuse, is required.
Electrical Rating: 115V, 60Hz, 10 Amps
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
Washer Note: Washer wall outlet must be located within 36" of
service cord entry. Wall outlet must not be located behind dryer.
Listed by
Underwriters
Laboratories
