Step 1:

Starting with the X450 in a default configuration state, create three VLANs to represent the following

roles in the network design:

1. VLAN to connect corporate IT resources including the amigopod server (in example Office)

2. VLAN to connect to the Internet or DMZ segment (in example Guest)

3. VLAN to temporarily place the unauthenticated visitors piror to VLAN move (in example

unsecured)

create vlan "guest"

configure vlan guest tag 30

create vlan "office"

configure vlan office tag 10

create vlan "unsecured"

configure vlan unsecured tag 20

Step 2:

Now assign switch ports to the Office and Guest VLANs so the amigopod server and Internet/DMZ

connection can be made:

configure vlan Default delete ports all

configure vlan guest add ports 17-24 untagged

configure vlan office add ports 1-8 untagged

Note: There is no requirement at this point to assign switch ports to the unsecured VLAN as this is done

explicitly during the configuration of the Web Login feature in subsequent steps.

Step 3:

Assign IP Addressing details to each VLAN and ensure that IP Forwarding is enabled for only VLANs

office and guest (not unsecured):

configure vlan office ipaddress 10.0.20.1 255.255.255.0

enable ipforwarding vlan office

configure vlan unsecured ipaddress 192.168.2.1 255.255.255.0

configure vlan guest ipaddress 192.168.1.10 255.255.255.0

enable ipforwarding vlan guest
