Dynex DX-32L200NA14 Quick Setup Manual

QUICK
SETUP GUIDE
32" LCD TV
DX-32L200NA14
Thank you
for purchasing this state-of-the-art
Dynex television. We hope you enjoy
the quality and reliability of this
television for years to come.
Included accessories
DX-RC01A-13
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.dynexproducts.com,
click Support & Service, enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click Search.
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: Phillips screwdriver and a soft surface to lay the TV on.
A Lay the TV down on a soft surface.
B Find the front of the stand. Attach it to the TV by hooking the slot in the stand
onto the tab on the stand column, then push the stand into place.
C Secure the stand to the TV with the six screws provided.
- OR -
How do I prepare my TV for wall mounting?
(not for use with a TV stand)
A Lay the TV down on a soft surface, then remove the four screws
from the stand column.
B Remove the stand column.
Which cables do you have?
Your TV has several different jacks for connecting devices. For the
STOP!
best video quality, use the best available connection. Use the cables
that came with your devices.
Do not plug your
power cable in until
all other devices have
VIDEO QUALITY
been connected.
BEST
BETTER
Component video and analog audio
GOOD
Composite video and analog audio
GOOD
Remote control
Note: You can use the HDMI 1/DVI jack to connect a DVI device to your TV. Attach an
and two AAA batteries
HDMI-to-DVI adapter to the end of the HDMI cable. The adapter connects to the DVI
device's jack. See your online User Guide for more information about different types of
HDMI.
Features
Front view
TV stand
Remote control sensor
Power indicator
Side view
Power connector
M4 screws
(16 mm length) (6)
Note: Images do not necessarily represent the exact design of your television.
Front
A
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) and/or connect a device such as
a DVD or Blu-Ray Disc player, game station, or camcorder?
Using an HDMI cable (BEST)
PORT TYPE CABLE CONNECTOR
HDMI video/audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
Note: Connect the yellow video
cable to the green Y/Video jack
on the back of your TV.
How do I connect my TV to an antenna or cable wall jack?
Before using your new product, please read these instructions to prevent any damage.
B C
B
Component
AUDIO/VIDEO
cable option
OUT
AV cable option
AV IN
L R
AUDIO
PC/DVI
VGA DIGITAL ANT
USB HDMI3 HDMI2 HDMI1/DVI AUDIO IN VIDEO/Y P B P R
AUDIO OUT OUTPUT CABLE IN
USB IN P C N I C O M P O N E N T N I
M4 (16 mm)
Multi-purpose ports: You can plug
any device that uses HDMI into the
HDMI DVI port. However, certain
devices must be connected to
HDMI DVI.
Note: The component and AV jacks
are shared. This means you can
connect only one component or AV
device at a time. We suggest using
HDMI if your device supports it.
CABLE
OVER
