Make sure the following items are included in the package. USB Cable RS-232/CVBS Cable RGB Cable Power Adapter RCA Cable DCP10 Power Cord Software & Manual CD * The power cord will vary depending on the standard power outlet of the country where it is sold.
R ig ht Pa ne l (fig. 1.2) Name Function USB Flash Drive switch Switch to right (►) for audio video recording directly to a USB flash drive and left (◄) when connecting DCP10 to a computer using a USB cable.
DC12V / LIGHTBOX port Connect the power adapter into this port. DVI-I OUTPUT port Connect the DCP10 to any display device with DVI cable. If the display device does not support DVI-I, you can only view in Camera and Playback mode.
Name Function SD card slot Insert the SD card with the label facing up. Cont rol Panel (10 ) (11) (12 ) (fig. 1.5) Name Function MENU Open and exit the OSD menu. RECORDING Start/Stop audio & video recording. Audio and video recording can be saved on a SD card or an USB Flash drive only.
Remote Cont rol The remote control requires two (2) “AAA” size batteries (supplied), make sure batteries are installed properly before use. You can access all the features of DCP10 with the remote. Name Function POWER Turn the unit on/standby. CAMERA / PC Switch between Camera and computer mode.
Page 8
Name Function (15) DEFAULT Reset at factory default setting. (16) NEAR / FAR Adjust the focus manually. (17) ZOOM RESET Reset zoom level to 100%. (26) (18) ZOOM +/- Increase/decrease the image (25) magnification in camera and picture (24) playback mode. (23) (19) ENTER - Make a selection in Playback mode...
DCP10 with. The TV-RGB switch determines the display output selection. Switch it to RGB (right) to output signal using RGB/DVI-I connection and TV (left) to output signal using RCA connection.
Locate the DVI-I input port of the display device and connect it to DVI-I OUTPUT port of DCP10. Make sure the TV/RGB switch is set to RGB. LCD Monitor with DVI interface DVI cable (not supplied) Projector Locate the VIDEO or SCART RGB (if applicable) input port of the TV or Video equipment (i.e., VCR) to record your presentation and connect it to RCA jack of RS-232/CVBS cable.
Power cord Locate the RGB (VGA) output port of the computer or laptop and connect it to RGB INPUT port of DCP10. The video signal from the RGB INPUT port is streamed to RGB and DVI-I OUTPUT port. - To display computer image, press Camera/PC button on the control panel or remote control to switch DCP10 to computer mode.
Locate the USB port of the computer or laptop and connect it to USB port of DCP10. This enables you to use DCP10 as a USB Camera or to transfer the captured pictures/videos from the memory and to computer. Also see “Transfer File from DCP10 to PC”.
Amplified Speaker Connect the DCP10 to a microscope enables you to examine microscopic objects on a big screen. Change the image display mode to Microscope. Press MENU > select MODE > select MICROSCOPE and press ENTER.
This section provides useful tips on how to adjust the DCP10 to meet your needs. The camera head can turn freely at 90° to the left and right and up and down. 90° 90° 90° 90° If the camera head is in upright position, you can also press ROTATE on the remote control twice to rotate the image in 180°.
DCP10 has patented four (4) laser positioning pointers feature that define the viewing area. This allows user quickly center the object underneath the camera. The three (3) various light and laser positioning pointers settings are indicated in the illustration below.
DCP10 supports both SD memory card and USB flash drive for more image capture and audio & video recordings. DCP10 can detect when there is an external storage media and automatically switch to the last detected storage. If no external storage is connected, all captured still images will be saved in the built-in memory.
There are 5 tabs on the OSD menu: BASIC, ADVANCED, PRESENTATION, SETTING and SYSTEM. In Playback mode, you can access PLAYBACK OSD menu to enable the Slide Show feature and modify Slide Show interval and transition setting if desire. For TV output, the RESOLUTION will be disabled in SETTING menu list. BASIC ADVANCED PRESENTATION...
1. Press MENU button on the remote or control panel. 2. Press ► and ◄ to toggle between tabs 3. Press ▼ and ▲ to select a menu option. 4. Press ENTER to make a selection and display the setting selection on the right. 5.
Menu Screen Function MODE Select various image display settings. Sharp - adjust the contrast along the edges making text appear more visible. Graphics - adjust the gradient of image. Motion - increase frame rate. Sufficient lighting is required when using this mode. Microscope - automatically adjust optical zoom for microscopic viewing.
Menu Screen Function Exposure Select the exposure setting. AUTO - automatically adjust the camera exposure and amount of light required. MANUAL - manually adjust the exposure level. The exposure can be adjusted up to 100. White Balance Select the White Balance setting for various light conditions or color temperature.
Menu Screen Function Night View Select to turn Night View OFF or AUTO. When presenting in a low-light condition, Night View enables brighter images by automatically adjusting the exposure and the frame rate will be reduced. Menu Screen Function QBOX On/Off QBOX overlays a frame on the presentation screen.
Menu Screen Function QBOX Resize Change QBOX frame size. The frame blinks when it is in resizable mode. Use the ▲,▼,◄, & ► buttons to adjust the frame size and press ENTER to set the desire size. QVISOR QVISOR covers the presentation screen. The upper part of the presentation screen is slightly exposed.
Function Split Screen Divide the screen into two parts. Half of the screen displays the 8-thumbnail images and the other half display the image from the DCP10 camera. Select the display location of the 8- thumbnail playback images. Left Right...
Menu Screen Function Capture Quality Select the capture compression setting. Capture Type Select the capture type. Single - capture one picture only. Continuous - capture successive pictures. Capture Interval Set the interval before capturing the next picture. The length can be set up to 600 sec (10 min). Recording Format Select the video recording format between MOV and AVI.
Menu Screen Function Current Storage Change the storage location. Audio & video recording can only be saved in SD memory card or USB flash drive. Built-in Memory SD Memory Card USB Flash Drive Format Storage Format to delete all the data in the selected memory. A Warning Message will appear.
Menu Screen Function USB State Select the status of the DCP10 when it is connected to the computer via USB. Make sure the USB Flash Drive switch is set to the left. USB Camera - can be used as a computer webcam or with our bundled software to record video and capture still image.
Menu Screen Function Information Display product code Menu Screen Function Slide Show Display all captured still pictures in an automated slide show. The video file will be skipped. Slide Show Interval Set the interval before displaying the next picture. The length can be set up to 100 sec.
3. When “Mass Storage Start…” appears at the lower right corner of the presentation screen, you may now connect the USB cable. 4. Upon connecting the USB cable, the system automatically detects the new removable disk. You can now transfer the captured image(s) from the DCP10 built-in memory to the computer hard disk.
RGB (VGA) output to RGB input of DCP10 and make sure DCP10 is in PC Mode. I have set up the DCP10 and checked all the connections as specified in the manual but I cannot get a picture on the preferred presentation screen.
4. After you follow these steps, you should be able to see the same desktop image on your PC or Notebook as well as on the presentation screen. DCP10 can’t detect the inserted USB flash drive. Make sure the USB flash drive switch is set to the right and check if the USB flash drive is properly inserted.
