Toshiba Satellite 2800-S102 Specifications

TOSHIBA
Satellite ® 2800 Series
Product Highlights:
Performance: Mobile Intel® Celeron™
processor 650MHz, 64MB SDRAM standard,
expandable to 320MB and a 6BB HDD
Connectivity: LAN- and Internet-ready with
10/100 Ethernet and V.90/K56flex modem
ports, allowing broadband access
Enhanced Multimedia: 13.3" TFT active
matrix display; 8X max. DVD-ROM, S3
Savage/IX graphics controller; and a
booming subwoofer for a full multimedia
experience
All-in-one, stylish design: built-in 8X DVD-
ROM, 6.0BB hard disk drive, and diskette
drive -- no swapping required
Productivity Tools: Toshiba Active Menu,
FreedomWare , and Toshiba Great
Software Offer
Advanced Service & Support: Toshiba's
suite of services is ready whenever and
VirtualTech™
wherever you are;
support, Toshiba software updates. Optional
SelectServ™
extended warranty,
SystemGuard and other programs to protect
your investment
Product Specification
Processor
Mobile Intel® Celeron™ processor 650MHz
128KB Level 2 cache integrated on die
Integrated co-processor
Data/Address Bus Width: 64-bit/32-bit
100MHz Front Side Bus
Memory
64MB, expandable to 320MB
Internal memory expansion slot
128 Mbit PC100 SDRAM . 3.3V
BIOS
APM V1.2; ACPI V1.0b; PnP V1.0a; VESA V2.0;
DPMS; DDC2b; SM BIOS V2.3, PCI BIOS V2.1
System Architecture
PCI Bus V2.2
Hard Disk
6.0 billion byte hard drive, Enhanced IDE, 2.5"
Service removable
9.5 mm height
13ms average access time
Supports PIO Mode4 or Ultra DMA33 Mode2
Diskette Drive
Built-in 3.5", 1.44MB
DVD-ROM
Built-in 8X max. speed
110ms average access time
4469/10816KB/sec maximum data transfer rate
(DVD Mode)
1545/3600KB/sec maximum data transfer rate (CD
Mode)
Compatibility: DVD-ROM, DVD-R, CD-ROM, CD-R,
CD-RW
Video
S3 Savage/IX Graphics Controller
64-BIT graphics accelerator
2x AGP bus
128 BitBLT hardware
8MB internal video memory
Display
13.3" diagonal (1024 x 768)
Internal display supports up to 16M colors at 1024
x 768
External Color Support
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2001 TAIS satellite_2800series_spec.doc Rev. 13 04/24/01
800 x 600 and 640 x 480; 60/70/85Hz Non-
Interlaced @ 16M
1024 x 768; 60/70/85Hz Non-Interlaced @ 16M
1600 x 1200; 60/70/85Hz Non-Interlaced @ 64K
Audio
Yamaha YMF754B-R
3D sound support with HRTF 3D positional audio
16-bit stereo, .WAV and Sound Blaster® Pro
compatible, MIDI playback
2 built-in stereo speakers with subwoofer
64-channel wavetable music synthesis
Full duplex sound support
Hardware acceleration for DirectMusic and
DirectSound
Microphone and Headphone ports
Communications
Integrated V.90/K56flex modem
Integrated 10/100 Ethernet
Keyboard
Full sized 85 keys with 12 function keys
2.7mm travel
on-line
Dedicated Windows® keys
Integrated AccuPoint® II pointing device with scroll
buttons
User Control Keys
Control buttons for CD/DVD playback functionality
Play / Pause
Stop / Eject
Next
Previous
Internet button
Expansion
Two PC Card slots support two Type II or one Type
III PC Cards
SVGA video port
TV-Output
PS/2™ mouse/keyboard port (Y-connector
supported)
Two Universal Serial Bus port
ECP parallel port
Headphone jack, Microphone port
RJ-11 port
RJ-45 port
Dimensions (LxWxH)
12.9" x 10.7" x 1.5"
Weight
7.30 lbs.
Power Supply
60W Autosensing External AC Adapter
100-240V input voltage
50-60Hz frequency
5.51"L x 2.95"H x 0.98"W, 0.7 lbs
Battery
Rechargeable, removable Lithium Ion battery
(10.8V, 4,000mAh)
2.0+ hours battery life
Recharge time: 3 hrs unit off, 4-10 hrs unit on
ACPI V1.0b support
Battery life may vary depending on applications,
power management settings and features utilized.
Recharge time varies depending on usage.
System Management
ACPI V1.0b Power Management
Toshiba Configuration Builder-customized software
image tool
Year 2000 Compliance: NSTL Hardware Tested
Security
Power-on password
Cable lock slot
SecureSleep (Screen Blank)
Keyboard Lock
Memory, HDD and Modem (by screw only)
Operating System
Microsoft® Windows Millennium Edition
Additional Software
Customizable Toshiba/My Yahoo! Start Page
Microsoft Internet Explorer
MediaMatics DVDExpress
Toshiba Custom Utilities
Satellite Series Online Documentation
Toshiba
VirtualTech™
Toshiba Great Software Offer: With each Satellite
notebook, you will receive your choice of two
software titles. The software selection includes
titles from the following: Lotus® SmartSuite
Millennium Edition, productivity, creativity
education/reference, and entertainment titles.
Warranty
1 year parts, labor and battery
Environmental Specifications
Temperature:
O O O
Operating: 5 to 35 C (41 to 95
O O
Non-operating: -20 to 65 C (-4
Thermal gradient:
O
Operating: 15 C per hour maximum
O
Non-operating: 20 per hour maximum
Relative Humidity:
Operating: 20% to 80% non-condensing
Non-operating: 10% to 95% non-condensing
Altitude (relative to sea level):
Operating: -60m to 3,000m (-197' to 9,842')
Non-operating: -60m to 10,000m (-197' to
32,808')
Shock:
Operating: 10G (11ms)
Non-operating: 60G (66ms)
Vibration:
Operating: 0.5G
Non-operating: 1G
Satellite 2800 Series Part Numbers and UPC
PS280U-8G5L06 Satellite 2800-S102
UPC: 032017068834
Recommended Accessories
PA2444U AC Adapter, 60W
PA2487URG Li-Ion Battery Pack
PA2488U Battery Charger
PA3053U-1PCC Bluetooth PC Card
WIN 98SE & ME only
KTT-SO100/32 32MB Memory
KTT-SO100/64 64MB Memory
KTT-SO100/128 128MB Memory
KTT-SO100/256 256MB Memory
NWCC38440 Standard Carryall, black
NWCC1344U Backpack, black
NWDEFCL Defcon notebook cable lock
PA070 USB port expansion hub
F3G117-01-NW Universal Y-adapter cable
TNABS-6.0GB 6.0GB Auto backup system
TNABS-12.0GB 12.0GB Auto backup system
TNABS-25.0GB 25.0GB Auto backup system
3CCFE575CT 10/100 Ethernet LAN card
(RJ-45)
3CXFE575CT 10/100 Ethernet LAN card
(Xjack)
O
F)
O O
to 149 F)
