Main Unit Disassembly Process

Main Unit Disassembly Flowchart

Figure 3-36. Main Unit DIsassembly Flowchart
Table 3-8. Screws
Step
Top Case and Palmrest
Disassembly
Touchpad Switch Board
Disassembly
Top Case Module Disassembly
Speaker Module Disassembly
Power Switch Board
Disassembly
Keyboard Bracket Disassembly
IO Board Disassembly
Motherboard Disassembly
Thermal Module Disassembly
3-26
Screw
M2.5*7
M2*3
M2*2
M2*3
M2.5*5
M2*2.2+5.7
M2*3
M2*3
M1.6*2.5
M2.5*5
M2.5*5
M2*3
Quantity Part No.
19
5
2
2
1
4
2
6
9
1
4
6
0
0
