Summary of Contents for Legacy Ultra MonoBloc
- Page 2 Registration 3. Owners Record Setup 4. Unit Connections 6. Unit Care Technology 7. Designer’s Note 9. Specifications...
- Page 3 Model No. _______________________________ Serial No. _______________________________ Date of purchase: _________________________ Thank you for selecting a Legacy Audio System. Please take a few moments to read this brief manual to insure maximum benefit from your electronic system.
- Page 4 To properly install the Ultra MonoBloc in your audio system, follow these brief steps. 1. Location To provide for adequate ventilation you should allow at least a couple of inches on each side of the amplifier. Because of its large power supply, the amplifier produces a local magnetic field that may be picked up by low level circuitry such as preamplifiers, turntables, and the like.
- Page 5 3. Input Connections Signal input from your preamplifier is made through one gold plated RCA (unbalanced) or one XLR (balanced) type connector. Do not use both RCA and XLR connectors at the same time as they will load each other improperly. 4.
- Page 6 The Ultra MonoBloc may overheat and the finish may fade if exposed to direct sunlight or intense heat sources for prolonged periods. Save your box and packing material; they may be necessary for moving or...
- Page 7 The Legacy Ultra MonoBloc is the most exquisite amplifier we have built. A balanced interconnection is provided to take advantage of the greater noise rejection it provides. Differential voltage gain throughout provides exceptional rejection of external noise and contributes to the inherent DC stability of the circuit.
- Page 8 The current stage is capable of producing peak currents in excess of 90 Amperes. This offers a degree of linearity and speed which is not matched by other designs when producing only a fraction of this current. This is achieved by the implementation of several distinct circuit features. The bias section is designed to produce a precision transition with no abrupt changes in distortion or output impedance.
- Page 9 Bandwidth: CD to -3dB @ 100 kHz Distortion: < .05% (actual type .025) Gain: 26dB Power Supply: 1700VA toroidal transformer and eight 10,000 µF 100 volt capacitors Noise: More than 100 dB referenced to rated output. Input Impedance: 50 k ohms unbalanced Output Impedance: 0.08 ohms from 20Hz to 20 kHz Slew Rate: 50 Volts/microseconds Rated Power:...
- Page 10 © 2003 Legacy Audio 150 Locust Street. Macungie, PA 18062 Phone: 610 965 0494 Fax: 610 965 4915...
