Summary of Contents for Legacy Step One
- Page 2 Registration 3. Owners Record Setup 4. Unit Connections 6. Using the Step One 7. Adjusting the Step One 8. Unit Care Technology 9. Designer’s Note 12. Specifications...
- Page 3 Model No. _______________________________ Serial No. _______________________________ Date of purchase: _________________________ Thank you for selecting a Legacy Audio System. Please take a few moments to read this brief manual to insure maximum benefit from your electronic system.
- Page 4 Single Ended Uniamplification Option 1: Preamplifier Processor Output to STEP ONE Unbalanced Input STEP ONE Unbalanced Variable Output to Processor Input Engage Processor Loop on Preamplifier Option 2: Preamplifier Output to STEP ONE Unbalanced Input STEP ONE Unbalanced Variable Output to Amplifier Input...
- Page 5 Single Ended Biamplification Preamplifier Unbalanced Output to STEP ONE unbalanced Input STEP ONE Unbalanced Fixed Output to High Frequency Amplifier Input STEP ONE Unbalanced Variable Output to Low Frequency Amplifier Input...
- Page 6 When uniamplifying using a single-ended stereo amplifier, STEP ONE can be used on an external processor loop of your preamplifier. It may also be inserted between your preamplifier and power amplifier. STEP ONE may also be placed on a tape monitor loop to “see” the effect of the unit; but for normal operation we recommend placing the environmental processor between your preamplifier and amplifier for optimum performance.
- Page 7 STEP ONE is a dramatic addition to your Legacy loudspeaker system. One of the most exciting features of the STEP ONE Processor is its flexibility. No matter what size your listening room, no matter what sensitivity differences may exist between your amplifiers, no matter how...
- Page 8 The Step One may overheat and the finish may fade if exposed to direct sunlight or intense heat sources for prolonged periods. Save your box and packing material;...
- Page 9 Easy to use, STEP ONE is inserted after your preamplifier. All you’ll need is one extra pair of interconnects. STEP ONE may also be placed in a tape loop for easy “before and after” comparison of adjustments. Its...
- Page 10 The cubic volume of your room determines how much your speaker’s output will be reinforced. STEP ONE provides a spectral control below 125 Hz, following the natural taper of room gain. For the first time, you’ll actually be able to match your system’s bass volume to your room’s cubic volume with the turn of a...
- Page 11 “air” as the low frequency resolution is restored. Like removing a cloud, you will hear the dimensionality that was there all along. Only the finest components are used throughout the STEP ONE Environmental Processor; French-built AXON capacitors, 1% tolerance resistors, hand-braided internal wiring, and an Alps Blue Velvet level control.
- Page 12 Frequency Response 10Hz to -3dB at 35 kHz Maximum Output 4.5 Volts peak Input Impedance 47.5k Ohms unbalanced 20.0k Ohms balanced Power Supply 80VA Toroidal transformer with 27,200 µF of capacitance Dimensions Height: 2.5” Faceplate, 3.0” Overall Width: 17.0” Faceplate, 17.0” Chassis Depth: 12.0”...
- Page 13 Notes:...
- Page 14 © 2003 Legacy Audio 150 Locust Street. Macungie, PA 18062 Phone: 610 965 0494 Fax: 610 965 4915...
