Summary of Contents for Rattler 369D

  • Page 1 M M o o d d e e l l 3 3 6 6 9 9 D D O O w w n n e e r r ’ ’ s s / / I I n n s s t t a a l l l l a a t t i i o o n n G G u u i i d d e e...

  • Page 2: L L I I M M I I T T E E D D L L I I F F E E T T I I M M E E C C O O N N S S U U M M E E R R W W A A R R R R A A N N T T Y Y

    l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics, Inc.
  • Page 3 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WAR- RANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.

  • Page 4: Table Of Contents

    t t a a b b l l e e o o f f c c o o n n t t e e n n t t s s l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y ................i i w w h h a a t t i i s s i i n n c c l l u u d d e e d d .
  • Page 5 timer mode ........... . 47 valet take-over .
  • Page 6 w w h h a a t t i i s s i i n n c c l l u u d d e e d d Control Module One 3-Button Transmitter 9-Pin Main H/1 Harness 5-Pin H/2 Secondary Harness 4-Pin External Relay HF+ External Receiver and Cable Shutdown Toggle Switch...

  • Page 7: System Maintenance

    Please take the time to carefully read this User’s Guide in its entirety and watch the Rattler Do-It-Yourself Installation Video prior to installing your system. You can print additional or replacement copies of this manual by accessing the Directed web site at www.diyrattler.com.

  • Page 8: Your Warranty

    your warranty Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validated if your warranty registration is not returned. Please note that it is necessary to keep your proof of purchase. fcc/id notice This device complies with Part 15 of FCC rules.
  • Page 9 1. Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage). 2. When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must be disabled using the toggle switch. 3.
  • Page 10 the vehicle starts in gear, cease remote start operation imme- diately and consult with the Dealer to fix the problem imme- diately. After the remote start module has been installed, test the remote start module in accordance with the Safety Check outlined in this installation guide.

  • Page 11: P P R R I I M M A A R R Y Y H H A A R R N N E E S S S S ( ( H H / / 1 1 ) ) , , 9 9 - - P P I I N N C C O O N N N N E E C C T T O O R

    p p r r i i m m a a r r y y h h a a r r n n e e s s s s ( ( H H / / 1 1 ) ) , , 9 9 - - p p i i n n c c o o n n n n e e c c t t o o r r H H 1 1 / / 1 1 LT.

  • Page 12: R R E E L L A A Y Y S S A A T T E E L L L L I I T T E E R R I I B B B B O O N N H H A A R R N N E E S S S S ( ( H H / / 3 3 ) ) , , 4 4 - - P P I I N N C C O O N N N N E E C C T T O O R

    r r e e l l a a y y s s a a t t e e l l l l i i t t e e r r i i b b b b o o n n h h a a r r n n e e s s s s ( ( H H / / 3 3 ) ) , , 4 4 - - p p i i n n c c o o n n n n e e c c t t o o r r H H 3 3 / / 1 1 BLUE...
  • Page 13 Be sure to read this section thoroughly and view the Rattler Do- It-Yourself Installation Video in its entirety before starting the installation.

  • Page 14: Step 1

    warning! Verify that the vehicle is set to park and that the parking brake is set before beginning installation. step 1 Ground Wire The BLACK wire on the main 8-pin harness is ground. This wire should be connected to a clean, paint-free area of metal in the drivers kick panel area.

  • Page 15: Step 2

    step 2 Constant Power and Ignition wires Almost all power and ignition wires can be found behind the key cylinder under the lower drivers side dash panel. Using the appropriate hand tools, remove the lower dash panel using care not to break any parts. If the panel does not come off easily check for any additional screws you may have missed.
  • Page 16 warning! Before making any connection to constant battery power make sure that the two green 30 amp fuses are removed from the fuse holders on the two thick red wires. Failure to do so may cause fire or shorting of sensitive electrical components. Once the constant power wire has been identified, solder the two thick RED wires from the control module to it and cover the connection with electrical tape to ensure a safe connection.

  • Page 17: Step 3

    If the wire tests correctly, solder the thick ORANGE wire off the relay satellite pack and secure it with electrical tape. If your vehicle requires more than one accessory contact Rattler Technical Support. © 2003 directed electronics, inc.

  • Page 18: Step 4

    Now that the accessories have been located, find the wire suspected to be the starter wire according to the web information on your vehicle. Place the red lead of your meter on the wire. With the key in the off position the meter should read 0.00 volts and will stay at 0.00 volts in all key positions except the crank position.
  • Page 19 and neutral safety wires. First locate the factory brake wire using your multi-meter. Find the switch at the top of the metal arm coming off the brake pedal. There are usually two wires connected to that switch. Locate the wire color according to the web information. With your black meter lead still in the kick panel, probe the suspected wire with the red lead of your meter.
  • Page 20 Installing the hood pin switch requires drilling a ¼-inch hole in the metal lip under the hood. Choose a location that will allow the pin switch to be depressed when the hood is closed. The pin switch has a connector on the bottom for the wire connection.
  • Page 21 warning! The vehicle may lunge forward when started if there is no factory safe- guards. Have the emergency brake engaged, and be prepared to quickly press on the brake and turn the engine off. The after-market safety switch will have two wires coming off it. Take one of the wires (it does not matter which one) and strip back a ¾-inch section of the insulation off the wire.

  • Page 22: Step 5

    There are several different types of parking light circuits. The following description is for a standard negative-triggered parking light circuit, usually located at the light switch. If the web vehicle information suggests a different type of parking light circuit, please contact Rattler Technical Support. © 2003 directed electronics, inc.

  • Page 23: Step 6

    Using the web information on the vehicle, locate the suspected wire and place the red lead of the meter to a constant (+)12 volt source and secure it. Place the multi-meter in the DC position. Using the black lead of the meter, probe the wire. With the switch in the off position the meter will read 0.00 volts.
  • Page 24 If your vehicle has a negative triggered door lock system, follow the steps below. If your vehicle has any other type of door lock system, please contact Rattler Technical Support to obtain the correct door lock wiring diagram.
  • Page 25 Once the correct wire has been found, solder the small LIGHT GREEN wire off the main connector to it and cover the connec- tion with electrical tape. Repeat this process for the unlock wire but press the switch to the unlock position when testing. Once you have identified the correct wire, solder the LIGHT BLUE wire off the main connector to it and cover the connection with electrical tape.

  • Page 26: Step 7

    The Rattler Do-It-Yourself system comes with a dual-relay pack included for door lock operation. To interface this piece with the system it is necessary to cut the three-pin plug off the relay module leaving the three wires long enough to connect to the system module.
  • Page 27 If the idle is too slow or too high, the system will shut down the engine to prevent damage. If the starter does not crank long enough to actually start the engine, it is possible to change the programming to extend the crank time. Refer to the Programming Options section of this guide.
  • Page 28 Valet/program button and turn the vehicle off. If the LED flickers or does not come on at all, an alternate tachometer wire will need to be found. Contact Rattler Technical Support for assistance. © 2003 directed electronics, inc.

  • Page 29: Step 8

    warning! Do not use a test light. Use of a test light can cause grounding of sensitive electrical components causing damage, including damage to the power train con- trol module. step 8 Factory Alarm Arm or Disarm Since most newer vehicles come equipped with a factory alarm system, it is necessary for the factory alarm to be armed/disarmed when unlocking the doors and disarmed while remote starting the vehicle.

  • Page 30: Step 9

    When the correct wire has been found, solder the small GREEN/BLACK wire to the wire which activates in the unlock position when the key is turned. Connect the GREEN/WHITE wire to the wire which activates in the lock position when the key is turned.

  • Page 31: Step 10

    To determine what bypass module your vehicle requires, check your web vehicle information sheet. step 10 Mounting the receiver/antenna The best location for the receiver/antenna is centered high on either the front or rear windshield. For optimal range, the antenna should be mounted vertically. It can be mounted hori- zontally in relation to the windshield or under the dashboard away from metal, but range will be diminished.

  • Page 32: Step 11

    step 11 Testing the system Once steps 1-9 have been completed, the operation of the system can be tested. Place the two 30-amp fuses back into the relay satellite red wire fuse holders. Make sure that the vehicle is in park with the emer- gency brake on and the hood closed.
  • Page 33 t t r r a a n n s s m m i i t t t t e e r r / / r r e e c c e e i i v v e e r r l l e e a a r r n n r r o o u u t t i i n n e e The system comes with one transmitter that has been taught to the receiver.
  • Page 34 button two Channel 2 button three Remote Start buttons one and two Timer mode button one and three Short-Run/Turbo CHANNEL NUMBER FUNCTION Auto-Learn Lock/Unlock Channel 2 output Remote Start Turbo/Short Run Timer Mode Delete all Transmitters 3. T T r r a a n n s s m m i i t t . While holding the Program switch, press the button on the transmitter that you would like to control the selected receiver channel.
  • Page 35 You can advance from programming one channel to another by releasing the Program switch and tapping it to advance steps and then holding it. For instance: You have programmed Channel One and you want to program Channel Two. Release the Program switch.
  • Page 36 change the settings. It is possible to access and change any of the feature settings using the Valet/Program switch. To program settings, remember: Key, Choose, Transmit and Release. To program the learn routine: 1. K K e e y y . Turn the ignition on and then back off.
  • Page 37 go out indicating the change. 4. R R e e l l e e a a s s e e . The Program switch can now be released. You can advance from feature to feature by pressing and releasing the Valet/Program switch the number of times neces- sary to get from the feature you just programmed to the feature you wish to access.
  • Page 38 f f e e a a t t u u r r e e s s m m e e n n u u Feature L L E E D D O O n n S S e e t t t t i i n n g g LED Off Setting The factory settings are indicated in bold text in the table below.
  • Page 39 f f e e a a t t u u r r e e d d e e s s c c r r i i p p t t i i o o n n s s 1 1 E E N N G G I I N N E E C C H H E E C C K K O O N N / / O O F F F F : In the default setting the remote start will monitor either the vehicle's tach wire or voltage depending on the programming of Feature 2.
  • Page 40 4 4 P P A A R R K K I I N N G G L L I I G G H H T T S S F F L L A A S S H H I I N N G G / / C C O O N N S S T T A A N N T T : : In the default setting, the unit will flash the vehicle’s parking lights while remote started.
  • Page 41 8 8 A A C C T T I I V V A A T T I I O O N N P P U U L L S S E E C C O O U U N N T T : : This feature allows the number of pulses to activate the remote start feature to be changed from 1, 2, or 3 pulses.
  • Page 42 1 1 4 4 . . I I G G N N I I T T I I O O N N C C O O N N T T R R O O L L L L E E D D U U N N L L O O C C K K : : When programmed ON the doors will unlock automatically when the...
  • Page 43 5. Press and release the Program switch. The LED will now report the last system shutdown by flashing for one minute in the following grouped patterns: The factory settings are indicated in bold text in the table below. Shutdown Mode Flashes System timed out Over-rev shutdown...

  • Page 44: Standard Configuration

    authorized dealer. Unless otherwise specified, the buttons used in all of the instructions in this manual correspond to a Standard Configuration transmitter. standard configuration B B u u t t t t o o n n The door locking and unlocking functions are controlled by pressing B B u u t t t t o o n n The channel 2 output or trunk release is controlled by the...

  • Page 45: Warning! Safety First

    u u s s i i n n g g y y o o u u r r s s y y s s t t e e m m warning! safety first The following safety warnings must be observed at all times: When properly installed, this system can start the vehicle via a command signal from the remote control transmitter.
  • Page 46 keys in the ignition. The user must also have the neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear. This testing should be performed by an authorized Directed Electronics, Inc. dealer in accordance with the Safety Check outlined in the product installation guide.

  • Page 47: Locking

    ELECTRONICS, INC.WILL NOT BE HELD RESPON- SIBLE OR PAY FOR INSTALLATION OR REINSTALLA- TION COSTS. locking Pressing for one second will lock the doors. The parking lights will flash once to confirm that the doors are locked. unlocking To unlock the doors press for one second.

  • Page 48: Remote Start

    remote start This feature allows you to remotely start and run your vehicle for a programmable period of time. This makes it possible to warm up the engine, as well as adjust the interior temperature of the vehicle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle.

  • Page 49: Short-Run/Turbo

    n n o o t t e e : : If the brake pedal is pressed before the key is in the ON posi- tion, the engine will shut down. While the vehicle is running during remote start operation, the system will monitor the vehicle and will automatically shut down the engine if the system receives any of the following shut- down inputs:...

  • Page 50: Timer Mode

    Press and release the buttons at the same time. The lights will flash to indicate the remote start has entered short run turbo mode. Turn off the key, the engine will keep running. Exit and secure the vehicle. The engine will turn off after the programmed run time. timer mode By pressing the remote buttons the parking...

  • Page 51: Valet Take-Over

    The system will start every 3 hours until canceled by the brake, hood, or neutral safety shut-down wires. Timer Mode should be used only in i i m m p p o o r r t t a a n n t t : : open areas.
  • Page 52 note: This feature will not work if the brake pedal is being pressed. p p r r o o g g r r a a m m m m i i n n g g o o p p t t i i o o n n s s Programming options control your system's normal, operational set-up.
  • Page 53 vating the unit with the ignition key in the “run” position. If the vehicle then runs normally, retest your ignition system. The starter continues to crank even though the engine has started. Has the tach wire been learned? See the Tach Learning section of this guide.
  • Page 54 after the remote start becomes active. If there is voltage present, skip to Step 4. If there is not voltage present, advance to Step 2. Check the 30A fuses. Make sure the purple starter wire is connected on the starter side of the optional starter kill relay.
  • Page 55 Was the Tach Learn successful? The LED must light solidly and brightly to indicate a successful learn. Make sure that there is a tach signal right at the purple/white tach input wire of the remote start. If not, recheck the connection to the vehicle’s tach wire and make sure the wire is not broken or shorted to ground leading to the remote start.
  • Page 56 g g l l o o s s s s a a r r y y o o f f t t e e r r m m s s The “brain” of your system. Usually hidden under Control Unit: the dash area of the vehicle.
  • Page 57 w w i i r r i i n n g g q q u u i i c c k k r r e e f f e e r r e e n n c c e e g g u u i i d d e e ©...
  • Page 58 n n o o t t e e s s _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ © 2003 directed electronics, inc.
  • Page 59 © 2003 directed electronics, inc.

  • Page 60: Quick Reference Guide

    QUICK REFERENCE GUIDE: To lock the doors using your remote Pressing for one second will lock the doors. The parking lights will flash once to confirm the doors are locked. To unlock the doors using your remote To unlock the doors, press for one second.
  • Page 61 © 2003 directed electronics, inc.
  • Page 62 © 2003 directed electronics, inc.
  • Page 63 The company behind this system is Directed Electronics, Inc. Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DIRECTED is ISO 9001 registered.
