- Page 1 421R Series Owner's Guide...
-
Page 3: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or replace (with a comparable reconditioned model), free of cost, any electronic control module which proves to be defective in workmanship or material under normal use, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY... - Page 4 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.
-
Page 5: Table Of Contents
Table of Contents Limited Lifetime Consumer Warranty ......i Standard Configuration Transmitter Diagram . -
Page 6: Standard Configuration Transmitter Diagram
Standard Configuration 2000 Directed Electronics, Inc. ©... -
Page 7: What Is Included
What is Included The control module A pair of two-button transmitters The red status LED indicator light A push-button Valet ® switch A Failsafe® Starter Kill relay on-board the control module Your warranty card Important Information Congratulations on the purchase of this system. It has been designed to provide years of trouble-free operation. -
Page 8: Your Warranty
Your Warranty Your warranty card must be returned and the barcode serial num- ber must not be removed. If the warranty card is not returned, no warranty will be honored on your unit. It is also necessary to keep your proof of purchase, which reflects that the product was installed by an authorized dealer. -
Page 9: Transmitter Functions
Transmitter Functions This system is programmable, making it possible to assign any trans- mitter button to any specific receiver function. The remote initially comes programmed with Standard Configuration, but may also be customized by an authorized dealer. The buttons in all of the instruc- tions in this manual correspond to a Standard Configuration remote. -
Page 10: Using Your System
Using Your System Locking/Arming Pressing for one second will lock the doors and activate the Failsafe ® Starter Kill. The red LED will begin flashing once per sec- ond and the parking lights will flash once. Pressing again within 10 seconds of locking/arming the system will not lock the doors again, but it will flash the parking lights and honk the horn once, confirming that the system is locked/armed. -
Page 11: Disarming The Starter Kill Without A Transmitter
did not unlock all vehicle doors, press again within 10 sec- onds to unlock the remaining passenger doors and the parking lights will flash twice. Pressing a third time within 10 seconds will flash the parking lights and honk the horn twice, confirming that the doors are unlocked and the starter kill is disarmed. -
Page 12: Panic Mode
Panic Mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your remote! Just press and hold for 1.5 seconds, and you will enter Panic Mode. The horn will honk and the parking lights will flash for 30 seconds. To stop Panic Mode at any time, press on the remote. -
Page 13: High Frequency
High Frequency Your system transmits and receives at 434 MHz. This provides a cleaner spectrum with less interference and a more stable signal. Enjoy a phenomenal increase in range, even in areas with high radio interference. Programming Options Programming options control what your system does during nor- mal operation, and require few or no additional parts. -
Page 14: Security & Convenience Expansions
Security & Convenience Expansions Here we have listed only some of the many expansion options available. Please consult your dealer for a complete explanation of all the options available to you. Domelight Supervision: If installed, the domelight will illuminate for 30 seconds each time the system is unlocked/disarmed using the transmitter. -
Page 15: Glossary Of Terms
Glossary of Terms Control Unit: The “brain” of your system. Usually hidden under- neath the dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all of the system func- tions. Failsafe ® Starter Kill: Located on-board the control module, this is an automatic switch controlled by the system which prevents the vehicle’s starter from cranking whenever the system is armed. - Page 16 Notes 2000 Directed Electronics, Inc. ©...
-
Page 17: Quick Reference Guide (Removable)
QUICK REFERENCE GUIDE: To lock/arm using your transmitter Pressing for one second will lock the doors and activate the Failsafe ® Starter Kill. The red LED will begin flashing once per second and the parking lights will flash once. Pressing again within 10 seconds of locking/arming the system will not lock the doors again, but it will flash the parking lights and honk the horn once, confirming that... - Page 20 The company behind this system is Directed Electronics, Inc. Since its inception, DEI® has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered.
