- Page 1 PowerClass SubWoofers PCX 102 PCX 104 PCX 122 PCX 124...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Congratulations ........3 Caution . -
Page 3: Congratulations
CONGRATULATIONS Thank you for choosing PrecisionPower woofers. Designed and engineered in the USA, this product combines innovative technology with the finest materials to consistently deliver Absolutely State of the Art performance, sound quality, reliability, and value. This ™ PrecisionPower product reflects our commitment to offer you unparalleled performance and quality for years of dependable service and listening enjoyment. -
Page 4: Specifications
SPECIFICATIONS Directed Part Number PCX 102 PCX 104 PCX 122 PCX 124 Model Number 28102 28107 28112 28117 Thiele/Small Parameters Fs ( 36.7 39.77 22.07 24.2 free-air resonance, Hz Vas ( 0.75 0.64 4.38 3.96 equivalent compliance, cu. ft. Vas ( 21.09... -
Page 5: Features
SPECIFICATIONS (Continued) Recommended Enclosures Typical sealed enclosure ( 1.25 1.25 cu. ft. SPL sealed enclosure ( cu. ft. Typical vented enclosure ( 1.25 1.25 cu. ft. Port Tuning ( Port Diameter ( 2.25 2.25 inside, in. Port Length ( Equivalent Square Port (in.) 2 x 2 2 x 2 2.3 x 2.3 2.3 x 2.3... -
Page 6: Wiring Configurations
WIRING CONFIGURATIONS The following illustrations provide guidelines on properly connecting your PrecisionPower woofer to a PrecisionPower amplifier for maximum power and performance using common parallel, and series/parallel wiring configurations. Recommended Amplifier Power 1 woofer 200 to 600 watts 2 woofers 400 to 1200 watts 3 woofers 600 to 1800 watts... - Page 7 Parallel—Two Speakers (dual 4 ohm voice coils) Two dual 4 ohm voice coil woofers with voice coils in parallel and the two woofers in parallel results in a 1 ohm load to the amplifier. 1. Connect the speaker in parallel by connecting the four positive (+) terminals together and the four negative (-) terminals together.
- Page 8 Parallel—One Speaker (dual 4 ohm voice coils) One dual 4 ohm voice coil woofer with voice coils in parallel results in a 2 ohm load to the amplifier. 1. Connect the speaker in parallel by connecting the two positive (+) terminals together and the two negative (-) terminals together.
- Page 9 Series-Parallel—Two Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Two dual 2 ohm voice coil woofers with voice coils in series and then parallel the two series woofers results in a 2 ohm load to the amplifier.
- Page 10 Series-Parallel—Three Speakers (dual 4 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Three dual 4 ohm voice coil woofer with voice coils of each woofer wired in series and then parallel the three woofers for a resulting 2.67 ohm load to the amplifier.
- Page 11 Series—One Speaker (dual 2 ohm voice coils) One dual 2 ohm voice coil woofer with voice coils in connected in series results in a 4 ohm load to the amplifier. 1. Connect the woofer in series by connecting the negative (-) of one terminal to the positive (+) terminal of the other coil.
- Page 12 Series-Parallel—Four Speakers (dual 4 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Four dual 4 ohm voice coil woofers should be wired with the voice coils on each woofer in series and then parallel the four woofers for a resulting 2 ohm load to the amplifier.
- Page 13 Series-Parallel—Four Speakers (dual 2 ohm voice coils) Note: Verify and ensure that the woofer wiring is connected as shown with the negative connection from the first woofer coil connected to the positive connection of the second woofer coil. Four dual 2 ohm voice coil woofers should be wired with the voice coils on each woofer in series and then parallel the four woofers for a resulting 1 ohm load to the amplifier.
-
Page 14: Enclosure Design
ENCLOSURE DESIGN This section gives the basic description for a sealed enclosure. PrecisionPower woofers are designed for sealed enclosures and vented enclosures. Sealed enclosures are generally considered the most versatile for all music types and are the easiest to build. They will also give high power handling with a wider range of frequencies. - Page 15 PCX 102 and PCX 104 Box Recommendations —External Dimensions— A = 12 in. B = 12 in. C = 11.5 in. —Internal Dimensions— A = 10.5 in. B = 10.5 in. C = 10 in. —Wall Thickness— All Sides = 0.75 in.
- Page 16 PCX 122 and PCX 124 Box Recommendations —External Dimensions— A = 16 in. B = 15 in. C = 13.5 in. —Internal Dimensions— A = 14.5 in. B = 13.5 in. C = 11.75 in. —Wall Thickness— All Sides = 0.75 in. —Box Parts—...
-
