Page 1: Table Of Contents
Congratulations PC PRO15 Specifications Introduction Speaker Cutaway Sealed Enclosure Sealed Enclosure Ported Enclosure CONTENTS (Click on a topic to view) Ported Enclosure Bandpass Enclosure Bandpass Enclosure PC PRO15 Dimensions PC PRO15 Response Graphs Additional Information Warranty... - Page 2 Congratulations and thank you... for choosing PrecisionPower audio epuipment. At PrecisionPower we proudly design, engineer and manufacture audio products at our facility in Phoenix, Arizona. Our award winning engineering team utilizes innovative technology to consistently deliver Absolutely State of the Art sound quality, reliability, and value.
-
Page 3: Pc Pro15 Specifications
POWERCLASS PRO15 Subwoofer PRO15 Specifications Normal Power Handling Voice Coil Diameter Voice Coil Type / Former Resonant Frequency Qts-Total Damping Qms- Mechanical Damping Qes- Electromagnetic Damping Vas- Equivalent Compliance Volume DC Resistance of V.C. Sensitivity (SPL at 1W) Linear Excursion... -
Page 4: Introduction
INTRODUCTION Your new PowerClass PRO15 Flat Piston subwoofer is part of an exciting line of loudspeakers which represent the extraordinary design achievements of the PrecisionPower Engineering Team. The PrecisionPower, PowerClass PRO Flat Piston subwoofers have been engineered from the ground up and are constructed at our factory in Phoenix from the finest materials available. -
Page 5: Speaker Cutaway
SPEAKER CUTAWAY RETURN TO CONTENTS... -
Page 6: Sealed Enclosure
Install the woofer into the enclosure using the 10-32 bolts (supplied). Once the enclosure is complete, it is time to connect the speaker wire coming from the subwoofer enclosure to your amplifier. Check that you use the proper wire for consistent polarity, positive and negative. - Page 7 SEALED ENCLOSURE Sealed speaker diagram Internal dimensions should be calculated to determine the correct box volume. Be sure to allow for speaker displacement and extra bracing (if used). RETURN TO CONTENTS...
-
Page 8: Ported Enclosure
(See Diagram) Cut the speaker hole out of the baffle board with a router. Use a guide or template whenever possible for a clean, accurate job; use a jig saw only if a router is not available. -
Page 9: Ported Enclosure
Ported speaker diagram Internal dimensions should be calculated to determine the correct enclosure volume. Be sure to allow for speaker displacement, extra bracing (if used), and port displacement (only the length of the port that is INSIDE the enclosure). It may be necessary to angle the port to fit your design. To... -
Page 10: Bandpass Enclosure
Using the supplied template, trace the appropriate circle and mounting hole pattern for your PrecisionPower subwoofer on the baffle board. Cut the speaker hole out of the baffle with a router. Use a guide or template whenever possible for a clean, accurate job; use a jig saw only if a router is not available. - Page 11 Bandpass speaker diagram Internal dimensions should be calculated to determine the correct enclosure volume. Be sure to allow for speaker displacement, extra bracing (if used), and port displacement (only the length of the port that is INSIDE the enclosure). It may be necessary to angle the port to fit your design. To...
- Page 12 POWERCLASS PRO15 Subwoofer Basic Working Dimensions for the PRO15 Outer Diameter Mounting Hole Diameter Mounting Depth (from bottom of top ring) Speaker Displacement PRO15 Sealed Enclosures Net Volume 1.5 cubic feet 2.50 cubic feet 3.5 cubic feet PRO15 Ported Enclosures Net Volume 1.50 cubic feet...
- Page 13 POWERCLASS PRO15 Subwoofer PRO15 Sealed RESPONSE CURVE PRO15 Ported RESPONSE CURVE *ACTUAL IN-CAR RESPONSE CURVE WILL VARY BASED ON CAR TYPE, WOOFER LOADING, AND ENCLOSURE DESIGN. PRO15 Bandpass RESPONSE CURVE *ACTUAL IN-CAR RESPONSE CURVE WILL VARY BASED ON CAR TYPE, WOOFER LOADING, AND ENCLOSURE DESIGN.
-
Page 14: Additional Information
Additional information The PowerClass PRO15 subwoofer will give you excellent results in enclosures from 1.5 cubic feet to over 3.5 cubic feet, ported or sealed. Our dealers are trained to achieve the highest level of performance from our products. If you are installing your new subwoofers on your own and... - Page 15 WA R R A N T Y Three-Year Limited U.S.A. Warranty This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. PrecisionPower warrants its products to be free from defects in materials and workmanship under normal use and service for a period of three (3) years from the date of original purchase when the unit is installed by an Authorized Dealer.
