Page 1: Table Of Contents
CONTENTS (click on a topic to view) Congratulations Functions Features and Specifications System Tuning Mounting Frequency Distribution Mounting System Diagram Wiring Troubleshooting Wiring Block Diagram Functions Warranty... - Page 2 Congratulations and thank you..for choosing PrecisionPower audio epuipment. At PrecisionPower we proudly design, engineer and manufacture audio products at our facility in Phoenix, Arizona. Our award winning engineering team utilizes innovative technology to consistently deliver Absolutely State of the Art performance, sound quality, reliability, and value.
-
Page 3: Features And Specifications
FEATURES / SPECIFICATIONS 4 Band Graphic Equalizer Preamp Line Driver Ultra-Wide Bandwidth Circuitry Adjustable Input Sensitivity Center-Detented Boost/Cut Controls 12dB Boost/Cut for Each Band Gold-plated RCA Input and Output Connectors PWM (Pulse Width Modulated) Power Supply Designed and Handcrafted in the U.S.A. S p e c i f i c a t i o n s Signal-to-Noise Ratio 102dB... -
Page 4: Mounting
Once a location has been chosen, securely mount the PEQ-114 using the two supplied brackets. There are two different sets of brackets included with your PEQ-114 . One set is used to flush mount the equalizer, as shown above. The other set is used for surface mount, as shown on the next page. - Page 5 T r e b screws provided. Faceplate of bracket blank for installer's individual needs. We suggest using a #6 metal screw. Predrill a hole in the Dimensions location desired to mount the PEQ-114. 6.75"W 3.20" L 0.95"H V o l P o w...
-
Page 6: Wiring
WIRING Factory Ground wire may need to be replaced if it is Positive frayed or broken. Battery Terminal Fuse must be installed within 18" of battery Run signal cables (RCAs) and remote turn-on lead down the opposite side of Drill a hole in the firewall the vehicle of the power and use a rubber grommet eject... - Page 7 Once you have routed the power, ground, and remote wires through the vehicle, it is time to connect the wires to the PEQ-114 . Be sure that you have not reconnected the ground cable to the negative post of the battery.
-
Page 8: Functions
Low (100 Hz) Boost/Cut control. 4. Mid Midrange (2 kHz) Boost/Cut control. 5. Treble Treble (6.5 kHz - 26 kHz, Shelving) Boost/Cut control. 6. Power LED Red light indicates power on. Volume Treble PEQ-114 Power 70 100 500 700 BACK TO CONTENTS... - Page 9 FUNCTIONS Input Power Sensitivity Input Output Precision Power PEQ-114 Made in USA 7. Input Sensitivity Sets input gain to match the output level from the source unit (See Page 8). 8. Input Gold plated RCA inputs. Plug in the RCA cables from the source unit here.
-
Page 10: System Tuning
This setting will minimize system background noise and prevents overloading the PEQ-114 . Adjusting Your Equalizer The four bands (Sub, Low, Mid, and Treble) on your PEQ-114 have been designed to adjust the frequencies that are most often out of balance in a car. -
Page 11: Frequency Distribution
FREQUENCY DISTRIBUTION FUNDAMENTAL NOTE HARMONIC OR OVERTONE 100 200 400 800 1.6 3.2 6.4 12.8 20K electric guitar acoustic guitar violin cello double bass trumpet french horn trombone tuba soprano sax tenor sax clarinet oboe flute piano synthesizer female vocal range male vocal range tympani kick drum... -
Page 12: System Diagram
VOLUME LEFT RIGHT FOWARD REVERSE Vo lu Po we PE Q- 11 4 Su b Lo w M id Tr eb PEQ-114 Preamp/Equalizer Passive Passive Tweeter Tweeter Crossover Crossover MidRange MidRange POWERCLASS ™ 4 channel Amplifier Front High Pass 100Hz... -
Page 13: Troubleshooting
TROUBLE SHOOTING NO SOUND Is the LED lit? Check Power and Remote turn-on wire Check Input cables for signal by for voltage. Make sure Ground wire is connecting them to the next secure. component in line. ANY SOUND NOW? Problem is in the Equalizer. See your Problem is elsewhere in the system. -
Page 14: Block Diagram
BLOCK DIAGRAM BACK TO CONTENTS... - Page 15 WA R R A N T Y Three-Year Limited U.S.A. Warranty This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. PrecisionPower warrants its products to be free from defects in materials and workmanship under normal use and service for a period of three (3) years from the date of original purchase when the unit is installed by an Authorized Dealer.
