  • Page 1 PAR–650 5 Band Paragraphic EQ...

  • Page 2: Features & Specifications

    INTRODUCTION Thank you for choosing PrecisionPower we proudly design and engineer the world’s finest audio products. Our award winning products utilize innovative design and technology to consistently deliver Absolutely State of the Art ™ This PrecisionPower ™ product reflects our commitment to offer you unparalleled versatility and quality for years of dependable service and listening enjoyment.

  • Page 3: Installation

    Built-in remote output with turn-on delay for switching on amps. 30V MOSFET switching power supply. Gold-plated RCA input/output jacks. Half-din chassis for ease of installation. INSTALLATION 1. Read this manual carefully and in its entirety before installing this equalizer. 2. Always disconnect the battery or remove the fuses for circuits you will be working on.
  • Page 4 retract with each press. IN and OUT Position - A knob is set to its in position when it is initially extended. To set a knob to its out position pull gently on the knob until a plainly-felt notched position is reached. NOTE: DO NOT use excessive force when using the adjustment knobs or damage to their release mechanism can result.
  • Page 5 crossover frequency for the dedicated subwoofer output between 30–400 Hz at 12dB/octave. High-Pass Output Frequency Control IN/FRONT OUT FREQUENCY - When in, this knob controls the high-pass crossover point for the front outputs between 30 Hz and 400 hz at 12dB/octave. OUT/REAR OUT FREQUENCY - When out, this knob controls the high-pass crossover point for the rear outputs between 30 Hz and 400 hz at 12dB/octave.

  • Page 6: Control Panel

    CONTROL PANEL REAR PANEL FEATURES Power Connector Remote Turn On Output - This output is intended to be the remote turn on for the system amplifiers and has a built-in delay. Two to three seconds after the PAR-650 receives a (+)12V turn on signal it will send a (+)12V turn on signal to the amplifiers.

  • Page 7: Rear Panel

    Power Fuse - This fuse protects the PAR 650 on-board electrical components. Never replace this fuse with one of higher value or damage to the PAR 650 could occur and result in loss of your warranty. Illumination Switch - This switch changes the front panel background lighting from BLUE to GREEN to match the vehicle dash or radio backlighting.

  • Page 8: Crossover And Filter Adjustments

    NOTE: If connecting more than one input source to the PAR-650, use the Source 1 gain controls to match the input level of both sources. Set the filter gains to the flat (center) setting. Complete all signal and power connections to the PAR-650. Turn the system on and increase the gain on the Source 1 inputs until audible distortion can be heard.

  • Page 9: System Diagram

    If the front and rear outputs have been set to high pass by setting the switch on the rear panel to the high pass setting, adjust the front crossover to the lowest possible setting with a minimum of distortion. Repeat for the rear speakers. At this time adjust the subwoofer frequency and volume to match the crossover settings for the satellite speakers.

  • Page 10: Specifications

    SPECIFICATIONS PRECISION POWER PAR-650 Filter Parameters Boost/Cut Filter Bandwidth Crossover/Range Signal-to-Noise Ratio Frequency Response Maximum Output Voltage Output Impedance Gain (all filters set flat) Total Harmonic Distortion Stereo Separation Input Sensitivity Input Impedance Operating voltage/fuse Remote Out Size (H x W x D)

  • Page 11: Limited Two-Year Consumer Warranty

    Warranty LIMITED TWO YEAR CONSUMER WARRANTY: Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of two years from the date of purchase from the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an authorized Directed dealer.
