EURORACK UB1204FX-PRO Technical Specifications
EURORACK UB1204
Ultra-Low Noise Design 12-Input 2/2-Bus Mixer with
Premium Mic Preamplifiers and Multi-FX Processor
Ultra-low noise design, highest possible headroom, ultra-transparent audio
4 state-of-the-art, studio-grade IMP "Invisible" Mic Preamps with 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs
Integrated digital stereo FX processor with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
Studio-grade stereo FX processor with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
Effective, extremely musical 3-band EQ plus switchable low-cut filter on all mono channels
8 balanced high-headroom line inputs with +4/-10 level selection on stereo channels
2 aux sends per channel: one pre/post fader switchable for monitoring/FX applications and one post fader (for internal FX or as external send)
Clip LEDs, mute/alt 3-4, solo and PFL functions on all channels
2 subgroups with separate outputs for added routing flexibility
2 multi-functional stereo aux returns with flexible routing
Balanced main mix outputs with gold-plated XLR connectors plus separate control room, headphone and 2-track outputs
Control room/headphone outputs with multi-input source matrix
2-track inputs assignable to main mix or control room/headphone outputs
Switchable +48 V phantom power for condenser microphones
Rack mount brackets included
Internal switch-mode power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response
plus lowest possible power consumption for energy saving
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany

Specifications

Mono Inputs
Microphone Inputs (IMP "Invisible" Mic Preamp)
Type
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resistance
@ 50 Ω source resistance
@ 150 Ω source resistance
Frequency response
Gain range
Max. input level
Impedance
Signal-to-noise ratio
Distortion (THD+N)
-PRO
XLR, electronically balanced,
discrete input circuit
-134 dB / 135.7 dB A-weighted
-131 dB / 133.3 dB A-weighted
-129 dB / 130.5 dB A-weighted
<10 Hz - 150 kHz (-1 dB),
<10 Hz - 200 kHz (-3 dB)
+10 to +60 dB
+12 dBu @ +10 dB gain
approx. 2.6 kΩ balanced
110 dB / 112 dB A-weighted
(0 dBu In @ +22 dB gain)
0.005% / 0.004% A-weighted
Line Input
Type
Impedance
Gain range
Max. input level
Fade-Out Attenuation (Crosstalk Attenuation)
1
Main fader closed
Channel muted
Channel fader closed
Frequency Response
Microphone Input to Main Out
<10 Hz - 90 kHz
<10 Hz - 160 kHz
1/4" TRS connector
electronically balanced
approx. 20 kΩ balanced
approx. 10 kΩ unbalanced
-10 to +40 dB
30 dBu
90 dB
89.5 dB
89 dB
+0 dB / -1 dB
+0 dB / -3 dB
