SERVICE
DUAL BAND Mobile Cellular Phone
1
4
GHI
7
PQRS
+
/
3
2
DEF
ABC
6
5
MNO
JKL
9
8
WXYZ
TUV
0
DUAL BAND Mobile
Cellular Phone
SGH-2200
Manual
CONTENTS
1. Exectrical Parts List
2. Exploded Views and Parts List
3. Block Diagrams
4. PCB Diagrams
5. Schematic Diagrams

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGH-2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SGH-2200

Summary of Contents for Samsung SGH-2200

  • Page 1 DUAL BAND Mobile Cellular Phone SGH-2200 SERVICE Manual DUAL BAND Mobile Cellular Phone CONTENTS 1. Exectrical Parts List 2. Exploded Views and Parts List 3. Block Diagrams 4. PCB Diagrams 5. Schematic Diagrams PQRS WXYZ...
  • Page 2 ELECTRONICS Samsung Electronics Co.,Ltd. GH68-00540A 1999.7. Rev.1.0...
  • Page 3 DUAL BAND Mobile Cellular Phone SGH-2200 SERVICE Manual DUAL BAND Mobile Cellular Phone CONTENTS 1. Exectrical Parts List 2. Exploded Views and Parts List 3. Block Diagrams 4. PCB Diagrams 5. Schematic Diagrams WXYZ PQRS...
  • Page 4 1. Exectrical Parts List Design LOC DESCRIPTION REMARK DIODE-SWITCHING,MCL4154 0401-001033 DIODE-ZENER,UDZ6.8B 0403-001172 DIODE-SCHOTTKY,PRLL5819 0404-001005 DIODE-SCHOTTKY,UPS5817 0404-001044 DIODE-SCHOTTKY,UPS5817 0404-001044 ZD12 DIODE-TVS,SM05 0406-001005 DIODE-TVS,SM12 0406-001012 ZD10 DIODE-TVS,SMS05C 0406-001051 DIODE-TVS,SMF05 0406-001084 DIODE-TVS,SMF05 0406-001084 DIODE-TVS,SMF05 0406-001084 DIODE-TVS,SMF05 0406-001084 DIODE-ARRAY,DAN222 0407-001002 DIODE-ARRAY,DAN222 0407-001002 DIODE-ARRAY,DA221 0407-001006 DIODE-ARRAY,UMN1 0407-001007 TR-SMALL SIGNAL,2SC4081...
  • Page 5 Design LOC DESCRIPTION REMARK IC-VOLTAGE REGULATOR,LP2982AIM5X-3.0 1203-001701 IC-VOLTAGE REGULATOR,LP2982AIM5X-3.0 1203-001701 IC-VOLTAGE REGULATOR,LP2982AIM5X-3.0 1203-001701 IC-VOLTAGE REGULATOR,LP2982AIM5X-3.0 1203-001701 IC-DC/DC CONVERTER,MAX1676 1203-001702 IC-DC/DC CONVERTER,LTC1555CGN 1203-001740 IC-DATA COMM.,AD6421AST 1205-001645 IC-COMM. CONTROLLER,AD6426XST 1205-001646 IC-TRANSCEIVER,HD155121F 1205-001653 IC-SYNTHESIZER,LMX2336LTMX 1209-001161 IC-ETC, LINEAR,HD155171T 1209-001208 THERMISTOR-NTC,47Kohm,5%,4050K,2.0mW/C,TP 1404-001005 VARISTOR.5.6V,-,1.6x0.8mm,TP 1405-001019 VARISTOR.5.6V,-,1.6x0.8mm,TP 1405-001019 VARISTOR.5.6V,-,1.6x0.8mm,TP 1405-001019...
  • Page 6 Design LOC DESCRIPTION REMARK R-CHIP,2.2Kohm,5%,1/16W,DA,TP,1005 2007-000141 R105 R-CHIP,2.7Kohm,5%,1/16W,DA,TP,1005 2007-000142 R130 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143 R-CHIP,8.2Kohm,5%,1/16W,DA,TP,1005 2007-000147 R101 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 2007-000148 R306 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 2007-000148 R307 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 2007-000148 R128 R-CHIP,15Kohm,5%,1/16W,DA,TP,1005 2007-000151 R283...
  • Page 7 Design LOC DESCRIPTION REMARK R-CHIP,0ohm,5%,1/16W,DA,TP,1005 2007-000171 R102 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R118 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R119 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R120 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R121 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R122 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R123 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R124 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R125 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R247 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R259 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R263 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 2007-000172 R264...
  • Page 8 Design LOC DESCRIPTION REMARK R114 R-CHIP,75KOHM,5%,1/16W,DA,TP,1005 2007-007021 R-CHIP,475Kohm,1%,1/16W,DA,TP,1005 2007-007098 R278 R-CHIP,18Kohm,1%,1/16W,DA,TP,1005 2007-007135 R158 R-CHIP,4.7Kohm,1%,1/16W,DA,TP,1005 2007-007136 R154 R-CHIP,1.2Kohm,1%,1/16W,DA,TP,1005 2007-007137 R-CHIP,27Kohm,1%,1/16W,DA,TP,1005 2007-007138 R111 R-CHIP,10Kohm,1%,1/16W,DA,TP,1005 2007-007142 R150 R-CHIP,10Kohm,1%,1/16W,DA,TP,1005 2007-007142 R277 R-CHIP,12Kohm,1%,1/16W,DA,TP,1005 2007-007309 R151 R-CHIP,22Kohm,1%,1/16W,DA,TP,1005 2007-007311 R157 R-CHIP,20Kohm,1%,1/16W,DA,TP,1005 2007-007312 R-CHIP,20Kohm,1%,1/16W,DA,TP,1005 2007-007312 R126 R-CHIP,6.8Kohm,1%,1/16W,DA,TP,1005 2007-007313 R127 R-CHIP,6.8Kohm,1%,1/16W,DA,TP,1005 2007-007313...
  • Page 9 Design LOC DESCRIPTION REMARK C-CERAMIC,CHIP,100pF,5%,50V,NPO,TP,1005,- 2203-000233 C-CERAMIC,CHIP,100pF,5%,50V,NPO,TP,1005,- 2203-000233 C100 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C102 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C103 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C104 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C105 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C106 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C107 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C125 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C217 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C225 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C226 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,- 2203-000254 C280 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005,-...
  • Page 10 Design LOC DESCRIPTION REMARK C134 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C135 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C136 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C137 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C139 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C140 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C142 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C143 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C240 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005,- 2203-000438 C122 C-CERAMIC,CHIP,1pF,0.25pF,50V,NPO,TP,1005,- 2203-000466 C189 C-CERAMIC,CHIP,1pF,0.25pF,50V,NPO,TP,1005,- 2203-000466 C207 C-CERAMIC,CHIP,1pF,0.25pF,50V,NPO,TP,1005,- 2203-000466 C176 C-CERAMIC,CHIP,220pF,10%,50V,X7R,TP,1005,- 2203-000585...
  • Page 11 Design LOC DESCRIPTION REMARK C166 C-CERAMIC,CHIP,3pF,0.25pF,50V,NPO,TP,1005,- 2203-000870 C167 C-CERAMIC,CHIP,3pF,0.25pF,50V,NPO,TP,1005,- 2203-000870 C211 C-CERAMIC,CHIP,3pF,0.25pF,50V,NPO,TP,1005,- 2203-000870 C-CERAMIC,CHIP,47pF,5%,50V,NPO,TP,1005,- 2203-000995 C289 C-CERAMIC,CHIP,47pF,5%,50V,NPO,TP,1005,- 2203-000995 C156 C-CERAMIC,CHIP,4pF,0.25pF,50V,NPO,TP,1005,- 2203-001017 C203 C-CERAMIC,CHIP,4pF,0.25pF,50V,NPO,TP,1005,- 2203-001017 C224 C-CERAMIC,CHIP,5.6nF,10%,25V,X7R,TP,1005,- 2203-001033 C200 C-CERAMIC,CHIP,820pF,10%,50V,X7R,TP,1005,- 2203-001221 C212 C-CERAMIC,CHIP,8pF,0.5pF,50V,NPO,TP,1005,- 2203-001259 C213 C-CERAMIC,CHIP,8pF,0.5pF,50V,NPO,TP,1005,- 2203-001259 C214 C-CERAMIC,CHIP,8pF,0.5pF,50V,NPO,TP,1005,- 2203-001259 C237 C-CERAMIC,CHIP,8pF,0.5pF,50V,NPO,TP,1005,- 2203-001259 C123...
  • Page 12 Design LOC DESCRIPTION REMARK C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C220 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C250 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C251 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C252 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C253 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C255 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C256 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C257 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C258 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C259 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C260 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C261 C-CERAMIC,CHIP,100nF,+80-20%,16V,Y5V,TP,1005, 2203-005061 C272...
  • Page 13 Design LOC DESCRIPTION REMARK C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C-CERAMIC,CHIP,1uF,+80-20%,10V,Y5V,TP,1608,- 2203-005065 C146 C-CERAMIC,CHIP,1.2pF,0.25pF,50V,NPO,TP,1005,0 2203-005234 C-FILM,CHIP,22nF,5%,16V,TP,3.2x1.6x0.8,- 2301-001199 C-FILM,CHIP,6.8nF,5%,16V,TP,2012,- 2301-001213 C-FILM,CHIP,10nF,5%,16V,TP,2012,- 2301-001230 C-FILM,CHIP,680pF,5%,50V,TP,2012,- 2301-001231 C-FILM,CHIP,470pF,5%,50V,TP,2012,- 2301-001232 C-FILM,CHIP,2.2nF,5%,50V,TP,2012,- 2301-001233 C263 C-TA,CHIP,3.3uF,20%,16V,-,TP,3216,- 2404-000335 C264...
  • Page 14 Design LOC DESCRIPTION REMARK INDUCTOR-SMD,4.7nH,0.3nH,1.0x0.5x0.5mm 2703-001747 INDUCTOR-SMD,4.7nH,0.3nH,1.0x0.5x0.5mm 2703-001747 INDUCTOR-SMD,4.7nH,0.3nH,1.0x0.5x0.5mm 2703-001747 INDUCTOR-SMD,4.7nH,0.3nH,1.0x0.5x0.5mm 2703-001747 INDUCTOR-SMD,4.7nH,0.3nH,1.0x0.5x0.5mm 2703-001747 INDUCTOR-SMD,3.9nH,0.3nH,1.0x0.5x0.5mm 2703-001751 INDUCTOR-SMD,10UH,20%,4.45X6.6X2.5MM 2703-001781 INDUCTOR-SMD,10NH,5%,1.0X0.5X0.5MM 2703-001786 INDUCTOR-SMD,10NH,5%,1.0X0.5X0.5MM 2703-001786 INDUCTOR-SMD,10NH,5%,1.0X0.5X0.5MM 2703-001786 INDUCTOR-SMD,3.3NH,0.3NH,1.0X0.5X0.5MM 2703-001790 OSC1 CRYSTAL-SMD,MC-156 2801-003760 OSC4 OSCILLATOR-VCO,VOU0540N30KRA 2806-001176 OSC3 OSCILLATOR-VCO,QVC101747RT-4042 2806-001195 OSC2 OSCILLATOR-VCO,QVC101615RT-4041 2806-001196 OSCILLATOR-VCTCXO13MHz,5ppm,10Kohm//10pF,TP,3V, 2809-001220 FILTER-EMI SMD,50V,300mA,-,470pF,2x1.25x0.5,T 2901-001116 FILTER-EMI SMD,50V,300mA,-,470pF,2x1.25x0.5,T...

  • Page 15: Table Of Contents

    2. Exploded View and its Parts List 2-1 Main Exploded View 2-2 Main Parts List 2-3 Test Zig 2-4 RF Cabel 2-5 Test Connection Method 2-6 Travel Adaptor 2-7 Travel Adaptor parts List 2-8 Ciger Light Adaptor 2-9 Ciger Light Adaptor Part List 2-10 Hands Free Kit Diagram 2-11 Hands Free Kit 2-11-1 Hands Free Kit Ass’y...

  • Page 16: Main Exploded View

    2-1 Main Exploded View Exploded View and its Parts List...

  • Page 17: Main Parts List

    2-2 Main Parts List DESCRIPTION SEC. CODE Q’TY REMARK TAPE WINDOW BOHO GH72-10001A LCD WINDOW GH72-00093A WINDOW TAPE GH74-00039A DUMMY KEY GH72-00108A DUMMY KEY TAPE GH74-00053A DUMMY FLIP GH72-00094A FLIP DUMMY FLIP TAPE GH74-00038A FLIP LOGO BADGE GH68-20008A FLIP COVER GH68-20008A FLIP HINGE HOUSING...
  • Page 18 2-3 Test Jig DEBUG : Cal, To.PC : Down Load Switch BOOT AUTO ON/OFF ON/OFF ON/OFF Cal. down Down Load 2-4 RF Cabel RF CABLE Exploded View and its Parts List...
  • Page 19 HP8922P POWER SUPPLY HP 83220E 3.8V RF IN/OUT SGH-2200 1 DEBUG : Cal, 2 To.PC : Down Load...

  • Page 20: Travel Adaptor

    2-6 Travel Adaptor 2-7 Travel Adaptor Parts List Type SEC Code Remark GH44-30548A CHINA GH44-30549A EUROPE GH44-30547A UNITED KINGDOM Exploded View and its Parts List...

  • Page 21: Ciger Light Adaptor

    2-8 Ciger Light Adaptor 2-9 Ciger Light Adaptor Part List Description SEC Code Remark Ciger Light Adaptor COde GH44-30546A BLACK Exploded View and its Parts List...

  • Page 22: Hands Free Kit Diagram

    2-10 Hands Free Kit Diagram Exploded View and its Parts List...

  • Page 23: Hands Free Kit

    2-11 Hands Free Kit 2-11-1 Hands Free Kit Ass’y MOUNTING BRACKET Exploded View and its Parts List...

  • Page 24: Hands Free Car Kit Option

    2-12 Hands Free Car Kit Option 2-12-1 Hands Free Car Kit Ass’y Phone Micro Phone Yellow(Ignition) White(Stereo Mute) Red(Vehicle Battery) Black(GND) Exploded View and its Parts List 2-10...

  • Page 25: Hands Free Kit Packing

    2-13 Hands Free Kit Packing 2-13-1 Hands Free Kit Packing Exploded View 2-11 Exploded View and its Parts List...
  • Page 26 2-13-2 Hands Free Kit Packing Parts List DESCRIPTION CODE Q’TY REMARK User Manual External Mic Power cable External speaker Cradle Install Bracket for cradle Hands free Box Install Bracket for hands-free box Unit Box Exploded View and its Parts List 2-12...
  • Page 27 3. Block Diagram 3-1 RF Block Diagram Block Diagram...
  • Page 28 Head set Buzzer Audio Interface Voiceband/Baseband Codec Mic. (AD642d1) Batteru Voltage I/Q BB Flash Audio Interface Filter Battery Temperature System RAM Ramp cont. Interface 13Mhz Clock Processor Serial Data Graphic Interface (AD6426) Interface 3V SYNTH I/O Interface 3V BRIGHT EEPROM SIM card +3V SIM Card Interface...
  • Page 29 3-3 DTC Block Diagram Block Diagram...
  • Page 30 Regulator Power Power DC/DC Current Stabilizer (12V-28V) Control Regulator Delector Voltage/Current Ignition Feed Back MICOM Data Communication EEPROM Calibration CODEC Microphone Volume Audio Speaker Control...
  • Page 31 4. PCB Diagram 4-1 Main PCB Top View PCB Diagram...
  • Page 32 Bottom View PCB Diagram...
  • Page 33 5. Schematic Diagrams 5-1 Power Management Schematic Schematic Diagrams...
  • Page 34 5-2 PSU Schematic Schematic Diagrams...
  • Page 35 5-3 B.B Charger Schematic Diagrams...
  • Page 36 5-4 LCD Schematic Schematic Diagrams...
  • Page 37 5-5 B.B Memory Schematic Diagrams...
  • Page 38 5-6 EVBC C295 39PF C294 39PF 51PF 47PF C289 47PF 100NF 100NF 100NF 100NF AGND4 AGND3 42 AVDD4 AGND2 AVDD3 AGND1 2 AVDD1 DGND4 37 DVDD4 DGND3 24 DVDD3 DGND2 11 DVDD2 Schematic Diagrams...
  • Page 39 5-7 EGSMP 2.2K 2.2K VDD10 GND10 VDD9 GND9 126 VDD8 GND8 VDD7 GND7 99 VDD6 GND6 VDD5 GND5 59 VDD4 GND4 VDD3 GND3 43 VDD2 GND2 VDD1 GND1 16 Schematic Diagrams...
  • Page 40 5-8 SIM Interface Schematic Diagrams...
  • Page 41 5-9 B.B Interface Connector Schematic Diagrams...
  • Page 42 5-10 VCTXO & DUAL Synthesizer Schematic Diagrams 5-10...
  • Page 43 5-11 BRIGHT IC & TXVCO GMDDIV MIX2OB 38 VCCDIV IOUT 23 39 RFLOIN IOUTB 22 GNDMIX1 QOUT 41 VCCMIX1 QOUTB 20 MIX1OUT GNDIQ 19 MIX1OUTB VCCIQ POONRX1 MODLB 17 POONRX2 46 POONTX IINB 15 47 MIX1INB2 QIN 14 MIX1IN2 QINB 5-11 Schematic Diagrams...
  • Page 44 5-12 LNA Schematic Diagrams 5-12...
  • Page 45 5-13 RF Transmitter DCSTX DCSRX GND1 GND9 GND2 C185 C166 R111 10K,1% C158 27PF 5-13 Schematic Diagrams...
  • Page 46 Schematic Diagrams 5-16...
