ROOM AIR CONDITIONER

Use & Care Guide
ACONDICIONADOR DE AIRE PARA HABITACIÓN
Manual de Uso y Cuidado
CLIMATISEUR DE PIÈCE
Guide d'utilisation et d'entretien
No.0010555512
For questions about features, operation/performance, parts,
Si tiene preguntas respecto a las características, funcionamiento,
rendimiento, partes, accesorios o servicio técnico,
Au Canada, pour assistance, installation ou service,
Model:
ESA424K ESA424K-L
accessories or service call: 1-877-337-3639
llame al: 1-877-337-3639
composez le : 1-877-337-3639

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESA424K-L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Haier ESA424K-L

Summary of Contents for Haier ESA424K-L

  • Page 1: Room Air Conditioner

    Manual de Uso y Cuidado CLIMATISEUR DE PIÈCE Guide d’utilisation et d’entretien Model: ESA424K ESA424K-L For questions about features, operation/performance, parts, accessories or service call: 1-877-337-3639 Si tiene preguntas respecto a las características, funcionamiento, rendimiento, partes, accesorios o servicio técnico,...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS AIR CONDITIONER SAFETY ............3 Using the Remote Control............11 INSTALLATION REQUIREMENTS..........3 Changing Air Direction ..............12 Tools and Parts ................3 Normal Sounds................12 Location Requirements ...............4 AIR CONDITIONER CARE ............12 Electrical Requirements ...............4 Cleaning the Air Filter ..............12 INSTALLATION INSTRUCTIONS...........5 Cleaning the Front Panel.............13 Unpack the Air Conditioner............5 Annual Maintenance..............13...

  • Page 3: Air Conditioner Safety

    AIR CONDITIONER SAFETY Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others.

  • Page 4: Location Requirements

    Electrical Requirements Location Requirements IMPORTANT: Observe all governing codes and ordinances. Check the location where the air conditioner will be installed. Make sure you have everything necessary for correct installation. The location should provide: ■ Grounded electrical outlet within 4 ft (122 cm) of where the power cord exits the air conditioner.

  • Page 5: Installation Instructions

    Power Supply Cord NOTE: Your air conditioner’s device may differ from the one shown. A. Test button B. Reset button This room air conditioner is equipped with a power supply cord required by UL. This power supply cord contains state-of-the-art To test your power supply cord: electronics that sense current leakage.

  • Page 6: Prepare Window For Installation

    NOTE: Cover putty knife blade with masking tape to guard Prepare Window for Installation against damage of the unit finish. Measure the width of the window opening. Mark the center line on the inside windowsill. A. Width of window opening B.

  • Page 7: Complete Installation

    Install left & right installation bracket and as shown in fig. Install outer case in window Install bolt(2 1/2” long flat head bolt and locknut) to the installation bracket and adjust them to proper length ,then use Place outer case in window. Lower sash until it rests behind 6 (13/32”)screws to fix the bracket on the case.
  • Page 8 2. Place the window lock bracket as shown. Use a 1⁄8” drill bit to drill a starter hole through the hole in the window lock bracket and into the upper window. 3. Attach the window lock bracket to the upper window with one 31⁄32”...

  • Page 9: Air Conditioner Use

    AIR CONDITIONER USE Operating your air conditioner properly helps you to obtain the ■ Do not try to operate your air conditioner in the Cool mode when outside temperature is below 61°F (16°C). The inside evaporator best possible results. coil will freeze up, and the air conditioner will not operate This section explains proper air conditioner operation.
  • Page 10 To set the Timer to turn on the air conditioner, changing Temperature the previous settings: 1. Turn on the air conditioner. ■ Press the TEMP/TIME up arrow button to raise the 2. Adjust the mode to Fan, Cool, Energy Saver or Dehum. temperature.

  • Page 11: Using The Remote Control

    Using the Remote Control NOTE: Remote control may differ in appearance. Temperature ■ Press the TEMP/TIME up arrow button to raise the ON/OFF temperature. Each time you press or hold the TEMP/TIME up arrow button, the temperature will go up 1ºF until it reaches 86°F (30°C).

  • Page 12: Changing Air Direction

    Adjust the temperature between 61ºF and 86ºF (16ºC and Changing Air Direction 30ºC). NOTE: In Fan mode, the temperature cannot be set. 4-Way Air Flow:The air directional louvers let you control the Press TIMER. Timer On indicator light on the air conditioner direction of the airflow to the desired direction.The airflow can be control panel will flash.

  • Page 13: Cleaning The Front Panel

    3. Use a vacuum cleaner to clean air filter. If the air filter is very dirty, wash it in warm water with a mild detergent. Do not wash the air filter in the dishwasher or use any chemical cleaners. Air dry the air filter completely before replacing to ensure maximum efficiency.
  • Page 14 ■ An extension cord is being used. Do not use an extension Air conditioner cycles on and off too much or does not cord with this or any other appliance. cool room in cooling mode ■ You are trying to restart the air conditioner too soon after turning off the air conditioner.

  • Page 15: Assistance Or Service

    Whenever you call to request service on your appliance, you need to know your complete model number and serial number. Keep this book and the sales slip together for future reference. In the U.S.A. Visit www.haieramerica.com or call Haier America toll For Further Assistance 1-877-337-3639. free:...

  • Page 16: Limited Warranty

    Haier America will repair or replace any mechanical, electrical part or the compressor, which proves defective in normal household use for a period of 12 months. Haier America will repair or replace (excluding labor costs) the sealed system and compressor (parts only) for an additional 4-year period.
