- Page 1 Instruction Instruction Manual Manual MODEL No. DTR-14D3 / 14D3VG / 14D3VGW 20D3 / 20D3VG / 20D3VGW 21D3 / 21D3VG / 21D3VGW 21D4 / 21D4VG / 21D4VGW 14D5 / 14D5VG / 14D5VGW 20D5 / 20D5VG / 20D5VGW 21D5 / 21D5VG / 21D5VGW 14D7 / 14D7VG / 14D7VGW 20D7 / 20D7VG / 20D7VGW...
-
Page 2: Identity Of Features On Localand Remote Control
IDENTITY OF FEATURES ON LOCALAND REMOTE CONTROL LOCAL CONTROL FRONT BACK VOLUME PROGRAMME VIDEO MAIN POWER VIDEO 2 HEAD STAND-BY REMOTE MENU TV/VIDEO DOWN/UP DOWN/UP BUTTONS BUTTONS BUTTON INPUT (MONO) PHONE INDICATOR SENSOR BUTTON (MONO) VIDEO 1 MONITOR REMOTE CONTROL... -
Page 3: Table Of Contents
CONTENTS * Identity of features on Local and Remote Control * Important safeguards * Installation After moving the set Inserting Batteries into the Remote Control Unit Aerial connection Mains connection Switching the set on and off Tuning the TV Channels Manual Channel Setting * Daily use Selecting a Programme Number... -
Page 4: Installation
INSTALLATION AFTER MOVING THE SET If the used set is moved or placed in a different direction, the MAIN POWER button must be switched off for at least 15 min- utes in order to take out a colour strain on the screen. INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT Press down the battery compartment grip and slide the cover. -
Page 5: Tuning The Tv Channels
TUNING THE TV CHANNELS MAIN MENU Main Menu Press the MENU button to call up the MAIN MENU. Picture The MAIN MENU consists of 5 SUB-MENUs: Woofer (option) Timer PICTURE, WOOFER(option), TIMER, LANGUAGE, PRESET Language To enter the MENU you must press OK button with the cursor Preset on that MENU. -
Page 6: Manual Channel Setting
MANUAL CHANNEL SETTING SEARCHING A CHANNEL Preset At first, the sound and colour system have to be set according the Manual Auto broadcasting system.(ex. B/D,AUTO-----). Enter a PRESET in the Fine Tune V/W MAIN MENU. With the cursor located on the MANUAL, press the RIGHT/LEFT Station : P01 - - - - button. -
Page 7: Daily Use
DAILY USE SELECTING A PROGRAMME NUMBER The set has a total of 100 programme numbers, 0..99. The NUMBER buttons 0..9 are used for direct programme selection. In order to select two-digit programme, press the second num- bered button within two seconds. Switch through the programme number step by step with the UP/DOWN buttons. -
Page 8: Timer
TIMER Enter TIMER in the MAIN MENU. Timer SETTING THE CLOCK Clock - - : - - With the cursor located on the CLOCK using UP/DOWN buttons, On Time - - : - - move it to first digit line with RIGHT/LEFT buttons. You can adjust the Off Time - - : - - time by selecting the proper digit with UP/DOWN buttons. -
Page 9: Recall
RECALL The RECALL button is used to display the current status: programme number, station name, clock.(left above), and system(right below). This display will appear for about 3 seconds unless any button is pressed. CHILD LOCK You can prevent the use of the TV set without the remote control. Press the ? button. -
Page 10: Local Control Key Mode
LOCAL CONTROL KEY MODE You can call up the MAIN MENU without the remote con- trol. You can enter the MAIN MENU directly by pushing the MENU button. If you press the MENU button, the MAIN MENU will be displayed on the screen. Move the cursor to the SUB MENU you want by using the VOL UP/DOWN but- ton and press the TV/VIDEO ( ) button, then the... -
Page 11: Game Mode
Game Mode 1. Contents of the game You have to make a complete shape of arrow by combining the blocks falling down randomly each of which is the part of arrow with the block piles on the ground. Then the arrow you have made just will be erased with the two blocks at the ends of it. - Page 12 P/N:48586490E102-R3...
