Before Setting Oven Controls ... 8-9 Before Setting Surface Controls ... 10 Setting Surface Controls ... 11 Oven Control Functions (540) ... 12 www.frigidaire.com USA 1-800-944-9044 & Care TA B L E O F C O N T E N T S Setting Oven Controls ...
If you do need service, help is only a phone call away. A list of toll-free customer service numbers are included in the back of this manual. Or call Frigidaire Customer Services at 1-800-944-9044, 24 hours a day, 7 days a week.
Ask your dealer to recommend a qualified technician and an authorized repair service. Know how to disconnect the power to the range at the circuit breaker or fuse box in case of an emergency. Save these instructions for future reference.
For electric ignition models only: Do not attempt to operate the range during a power failure. If the power fails, always turn off the range. If the range is not turned off and the power resumes, the range will begin to operate again.
• Use care when opening oven door , warmer drawer or lower oven door—Stand to the side of the range when opening the door of a hot oven. Let hot air or steam escape before you remove or replace food in the oven.
Conversion to Liquefied Petroleum Gas WARNING Personal injury or death from electrical shock may occur if the range is not installed by a qualified installer or electrician. Any additions, changes or conversions required in order for this appliance to satisfactorily meet the application needs must be made by a qualified technician.
30. Leveling legs and anti-tip bracket (included). Note: The features shown for your appliance may vary according to model type & color. Be sure to visit us online at www.frigidaire.com for a complete line of accessories. FEATURES AT A GLANCE TIMED CHICKEN NUGGETS...
BEFORE SETTING OVEN CONTROLS Oven vent location The oven vent is located below the control panel (See Fig. 1). When the oven is on, warm air passes through this vent. This venting is necessary for proper air circulation in the oven and good baking results. Do not block the oven vent.
3. Place the oven rack in positions 2, 3 or 4 only (see previous page to verify positions).Be sure the rack connector brackets are at the rear of the range and pointing towards oven bottom (See Fig. 2). 4. Assemble one connector arm at a time. With the oven...
IMPORTANT Do not place aluminum foil, or ANY material that can melt on the range cooktop. If these items melt they may damage the cooktop. NOTE The size and type of utensil used, and the amount and type of food being cooked will influence the settings needed for best cooking results.
OVEN CONTROL FUNCTIONS READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various pad functions of the oven as described below. bake time — Use timer on / to enter the off —...
Setting the clock When the range is first powered up, “12:00” will flash in the display (See Fig. 1). To set the clock to 1:30: Step 1. Press set clock. 2. Enter 1:30. 3. Press start. NOTE It is recommended to always set the clock for the correct time of day before using the appliance.
SETTING OVEN CONTROLS Setting a silent control panel Silent mode allows the oven control to operate without sounds. The control may be programmed for silent operation and later returned to operating with all the normal sounds. To set silent mode: Step 1.
Setting quick preheat Use the quick preheat feature when using single rack baking to quickly heat the oven to bake temperatures. Use this feature only for standard baking. A reminder tone will sound indicating when to place the food in the oven. When the oven is finished preheating quick preheat will become just like the bake feature and continue to bake until cancelled.
SETTING OVEN CONTROLS To program oven for delay start time and to shut-off automatically The delay start feature allows you to set a start and end time to the cooking process. Prior to setting a delay start, be sure the time of day is set correctly. If the delay start needs to be set more than 12 hours in advance (12-24 hours), the control must first be programmed for 24 hour display mode.
Convect (all models) Benefits of the convect features — Foods may cook up to 25 to 30% faster, saving time and energy. — Multiple rack baking. — No special pans or bakeware needed. Convect uses a fan to circulate the oven's heat uniformly and continuously around the oven.
SETTING OVEN CONTROLS Setting convect (convection) convert The convect convert feature allows you to convert any baking recipe using the convect (convection) feature. The control uses the normal recipe settings and adjusts to a lower temperature for convection baking. Convect convert can only be used with the convect bake feature.
Broil Use the broil feature to cook meats that require direct exposure to flame heat for optimum browing results. When broiling always remember to arrange the oven racks while oven is still cool. Position the oven rack as suggested in the broil settings table (See Fig. 4). To set broil: Step 1.
SETTING OVEN CONTROLS Setting pizza feature For your convenience the pizza feature provides 2 different settings. You may use the pizza feature whether starting with fresh or frozen pizza. To set the pizza feature: Step 1. Press pizza once to cook frozen pizza (Fig.1) or twice when setting for fresh pizza (Fig.
Adjusting the oven temperature Your appliance has been factory calibrated and tested to ensure an accurate baking temperature. For the first few uses, follow your recipe times and temperature recommendations carefully. If you think the oven is cooking too hot or too cool for your recipe times, you can adjust the control so the oven cooks hotter or cooler than the temperature displayed.
SETTING OVEN CONTROLS To Set the Sabbath Feature Jewish Sabbath & Holidays) For further assistance, guidelines for proper usage and a complete list of models with the Sabbath feature, please vist the web at http:\\www.star-k.org. WARNING FOOD POISONING HAZARD. Do not let food sit for more than one hour before or after cooking.
To Set the Sabbath Feature (cont’d) To turn off the oven but keep the Sabbath feature active: Press cancel. To turn off the Sabbath feature: Press and hold both the bake time and delay start pads for at least 3 seconds. The control will beep and SAb will disappear from the display.
Clean with soap and water. These areas are shown in white (See Fig. 1). CAUTION During the self-cleaning cycle, the outside of the range can become very hot to the touch. DO NOT leave small children unattended near the appliance.
Whenever the self-clean feature is active you may check the amount of time remaining in the self-clean cycle by pressing the locked until the range has cooled sufficiently. You will need to allow about 1 additional hour to the time displayed before you can open the oven door.
6. The clock will then need to be reset. To reset, see “Setting the clock” in this Use & Care Guide. CAUTION Be sure the range is unplugged and all parts are COOL before replacing oven light. Wear a leather-faced glove for protection against possible broken glass.
CARE & CLEANING Removing and replacing the lift-off oven door CAUTION The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down. To remove oven door: 1. Open oven door completely (horizontal with floor - See Fig.
Care & Cleaning section for additional cleaning instructions. • Range power cord is disconnected from outlet (electric ignition models only). Be sure power cord is securely plugged into the power outlet. • Electrical power outage (electric ignition models only). Burners can be lit manually.
• Be sure the light is secure in the socket. Also see “Changing & replacing the oven light” section. • Be sure floor is level, strong & stable enough to adequately support range. • If floor is sagging or sloping, contact a carpenter to correct the situation.
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
