(24) PREDELAY: This knob adjusts the predelay time. It adds a delay to the wet signal to
simulate distance and produces rhythmic effects. When the
knob operates in lengths related to the tempo. The values for sync are 1/32, 1/16T, 1/32.,
1/16, 1/8T, 1/16., 1/8, 1/4T, 1/8., 1/4, 1/2T, 1/4., 1/2, 1/1T, 1/2., 1/1.
(25) WIDTH: This knob adjusts the stereo image. Position 0 sums the input into a mono
signal and convolves it with the IR (mostly 2-channel samples). In this case, all stereo in
formation comes from the IR. Position 1 convolves the left side of the input with the left
side of the IR and the right side of the input with the right side of the IR. The knob cross-
fades between these signal flows.
(26) DEPTH: This knob simulates the depth of the room, bringing it closer or further away
by increasing or decreasing the early reflections in the IR. Using this control once the
START
knob is turned produces interesting results. It has little effect in Reverse mode.
(27) PAN: This does a psychoacoustic panning of the wet signal. Turn this knob to the left
to make the wet signal pan left, simulating the acoustics of shifting the reflections to the
left. Turn the knob to the right to cause the wet signal to pan right.
(28) Processing Indicator light: This light tells you when REFLEKTOR is processing a new
IR. When a knob is turned, the tail of the old IR is still processed and a new IR is started
for the change. The light then turns on. If another parameter is changed while the light is
on, the first IR is cut and the new change is started immediately.
(29) Category Picture: This is the picture for the IR category. This will display a picture
(.png file type only) that is in the same folder as the loaded sample. If a picture with the
same name as the sample is not found it looks for one with the name of the folder. If noth
ing is found the default picture is loaded.
Decay, Size, Start, Reverse Position, Low Frequency Envelope, Frequency for LO-ENV, High
Frequency Envelope, Frequency for HI-ENV, Predelay, Depth and Pan parameters cannot be
modulated because the IR needs to be recalculated for a new value that is not real-time. If a
MIDI controller is assigned you can adjust the parameter, but it is not intended to be used as
a performance control.
REFLEKTOR Interface and Controls
SYNC
button is pressed, the
REFLEKTOR - Manual - 10
