- Page 1 BRC Series BRC-H700 BRC-Z700 BRC-300 BRC-300P...
- Page 2 BRC Series can be controlled over long distances via a single fiber optic cable connection. With a number of useful features and excellent picture quality, the BRC Series is ideal for a variety of remote video shooting applications, such as in houses of worship, auditoriums, teaching hospitals, corporate boardrooms, and at sporting events, trade shows, and concerts.
- Page 3 • BRC-Z700: HD Component (Y/Pb/Pr), RGB, Composite, Y/C • BRC-300/300P: Composite, Y/C What’s more, each camera in the BRC Series has a wide range of optional interface cards to choose . Larger Pixel Size Compared to ClearVid CMOS Sensor from. This versatility allows for flexible analog and Conventional CMOS Sensor .
-
Page 4: Rear Panel Layouts
(VISCA protocol) Flexible Installation System integrators can easily configure complex systems with the BRC Series because each camera is Because the BRC Series has an “Image Flip” function, equipped with RS-232C/RS-422 interfaces supporting the unit can either be mounted on a ceiling using the... - Page 5 ø 8 (207) BOTTOM BOTTOM (102) - 20 UNC - 20 UNC (110) (98) Units: inches (mm) Units: inches (mm) BRC-300/BRC-300P BRC Series Pan/Tilt Ranges FRONT SIDE PAN RANGE (90) (9.6) (180) (205) BOTTOM TILT RANGE - 20 UNC (106) (147.6)
-
Page 6: System Configurations
SYSTEM CONFIGURATIONS Small Scale System Optional Video cards Projector Recorder Video Signal BRC Series Monitor IR Remote Commander Unit Large-screen Display Medium-sized System Optional Video cards Projector Video Signal Monitor Recorder BRC Series RS-232C / RS-422 RM-BR300 Remote Control Unit... -
Page 7: Optional Accessories
OPTIONAL ACCESSORIES BRBK-H700 HFBK-HD1 HFBK-SD1 HFBK-XG1 HD Interface Board XGA Interface Board HD Optical Multiplex Card SD Interface Board HFBK-TS1 BRBK-MF1 BRBK-HSD1 BRBK-303 i.LINK (HDV) Interface Board HD Optical Multiplex Card HD/SD-SDI Output Card SD Optical Multiplex Card BRC-H700 BRC-Z700 BRC-300 BRBK-301 BRBK-302... -
Page 8: Specifications
SPECIFICATIONS BRC-H700 BRC-Z700 BRC-300 BRC-300P Camera Signal systems 1080/59.94i or 1080/50i (switchable) 1080/59.94i, NTSC or 1080/50i, PAL (switchable) NTSC Sync systems Internal/External Image device 1/3-type IT CCD x 3 1/4-type CMOS x 3 1/4.7- type CCD x 3 Total picture elements Approx.
