Figure 3-1
Active
environment
Engines
Main
viewing
panel

Main Viewing Panel

The main viewing panel displays all configured engines in an iPlanet UDS
environment. Engines are shown with icons representing the state of each engine:
Off
Transition
Online
Error state
Most tasks you perform using the iIS Console are initiated by first selecting an
engine from the main viewing panel and then selecting the desired operation from
the appropriate menu.
iIS Console Main Window
Engine is configured but has not been started.
Engine is in the process of starting up or shutting down.
Engine has fully started and is online.
Engine has encountered an exception while attempting to start.
The iIS Console Main Window
Menu bar
Popup menu
Chapter 3 The iIS Console 69
