Vax Essentials VEU-01 Instruction Manual page 2

Vax VEU-01_02 User Guide.qxd
Vax V-015
1. Diagram
1
2
3
4
5
6
7
8
9
Fig.1/1
1 Handle
2 TurboTool (VEU-02 only)
3 Dirt container lid
4 Dirt Container
5 Extension tube
6 Dirt container release button
7 Crevice tool
8 Carpet height adjuster
9 Wheel
10 Filter
11 Vacuum head
2
parts overview
16/4/07 13:46 Page 2
12
13
14
10
15
11
12 Dusting Brush
13 Hose
14 Power Cord
15 Handle release pedal
16 Upper cord wrap with quick release
17 Hose connector
18 On/ off switch
18
16
17
