TECHNICAL NOTE
Importing Sounding Data
to DigiCORA® 3.64
M211299EN-B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DigiCORA 3.64 and is the answer not in the manual?

Questions and answers

Related Manuals for Vaisala DigiCORA 3.64

Summary of Contents for Vaisala DigiCORA 3.64

  • Page 1 TECHNICAL NOTE Importing Sounding Data to DigiCORA® 3.64 M211299EN-B...
  • Page 2 The contents are subject to change without prior notice. Please observe that this manual does not create any legally binding obligations for Vaisala towards the customer or end user. All legally binding commitments and agreements are included exclusively in the applicable supply contract or Conditions of...

  • Page 3: Table Of Contents

    Importing RC Tables ............. 9 Creating Parameter Use2010CalculationForTU ....10 CHAPTER 3 SIMULATING ARCHIVED OZONE DATA........... 13 Exporting Ozone-OIF92 ............13 Simulating Archived Ozone Data.......... 15 Exporting Parameters Subkey from Archived Sounding Data..................15 Importing Ozone-OIF92 and Parameters......18 VAISALA ________________________________________________________________________ 1...
  • Page 4 TECHNICAL NOTE _________________________________________________________________ This page intentionally left blank. 2 ___________________________________________________________________ M211299EN-B...

  • Page 5: Chapter 1 General Information

    DigiCORA version 3.64. - Chapter 3, Simulating Archived Ozone Data, explains how to simulate old ozone data with later versions of DigiCORA sounding software. VAISALA ________________________________________________________________________ 3...

  • Page 6: Version Information

    TECHNICAL NOTE _________________________________________________________________ Version Information Table 1 Manual Revisions Manual Code Description M211299EN-B September 2011. Importing ozone data added. M211299EN-A November 2010. This manual is valid from DigiCORA version 3.64 onwards. Related Manuals Manual Code Manual Name M210489EN DigiCORA® Technical Reference Documentation Conventions Throughout the manual, important safety considerations are highlighted as follows:...

  • Page 7: Recycling

    United States and/or other countries. License Agreement All rights to any software are held by Vaisala or third parties. The customer is allowed to use the software only to the extent that is provided by the applicable supply contract or Software License Agreement.
  • Page 8 TECHNICAL NOTE _________________________________________________________________ This page intentionally left blank. 6 ___________________________________________________________________ M211299EN-B...

  • Page 9: Simulating Old Sounding Data With The New Calculations

    Systems MW31 and MW21. Exporting RCTables To calculate sounding data using the improved calculation features you must first save the subkey called RCTables under database key SYSPAR to DigiCORAIII directory. Follow the steps below to save the subkey: VAISALA ________________________________________________________________________ 7...
  • Page 10 TECHNICAL NOTE _________________________________________________________________ In DigiCORA user interface, click System Settings and Connect. DbManager opens. Click SYSPAR and select RCTables. Right-click and select Export. 1011-076 Figure 1 Exporting RCTables Save the subkeys under RCTables to directory DigiCORAIII: 1011-077 Figure 2 Saving RCTables 8 ___________________________________________________________________ M211299EN-B...

  • Page 11: Calculating Old Sounding Data

    Open Archive Manager and select the sounding you copied. Click Parameters. Click SYSPAR. Right-click and select Import. 1011-078 Figure 3 Importing RCTables Select the RCTables file you saved earlier. The RCTables subkey will appear under the SYSPAR key and it replaces the old RCTables subkey. VAISALA ________________________________________________________________________ 9...

  • Page 12: Creating Parameter Use2010Calculationfortu

    TECHNICAL NOTE _________________________________________________________________ Creating Parameter Use2010CalculationForTU When you have added the new RCTables keys under SYSPAR, click the PTUEditing key. Right-click and select Create Value. 1011-079 Figure 4 Creating Value 10 __________________________________________________________________ M211299EN-B...
  • Page 13 Value Name text field. For Type, select SZ. Type Yes in the Data text field. 1011-080 Figure 5 Entering New Value Name Click OK. The parameter appears under the list of Value Names: 1011-081 Figure 6 New Value Name VAISALA _______________________________________________________________________ 11...
  • Page 14 TECHNICAL NOTE _________________________________________________________________ Open Archive Manager and select Simulate. You can now use the new parameter and the improved calculations to calculate old sounding data. 12 __________________________________________________________________ M211299EN-B...

  • Page 15: Simulating Archived Ozone Data

    Before importing subkey Ozone-OIF92 from the new software, you must first save the current subkey Ozone-OIF92. Follow the steps below to export and save the current subkey: In DigiCORA user interface, click System Settings and Connect. DbManager opens. VAISALA _______________________________________________________________________ 13...
  • Page 16 TECHNICAL NOTE _________________________________________________________________ Click SYSPAR and select Triggering - Ozone-OIF92. Right- click and select Export. 1109-021 Figure 7 Exporting Ozone-OIF92 14 __________________________________________________________________ M211299EN-B...

  • Page 17: Simulating Archived Ozone Data

    Archived Sounding Data Follow the steps below to export and save the Parameters subkey from archived sounding data: In DigiCORA user interface, open the Archive Manager by clicking the Archive Manager button on the left. The Archive Manager opens. VAISALA _______________________________________________________________________ 15...
  • Page 18 TECHNICAL NOTE _________________________________________________________________ Select a the sounding whose data you wish to import and click the Parameters button on the right. 1109-027 Figure 9 Archive Manager The DbManager opens.Click SYSPAR open and select Triggering - Ozone-OIF92 - Parameters. Right-click and select Export. 1109-018 Figure 10 Exporting Parameters...
  • Page 19 Chapter 3 ______________________________________________ Simulating Archived Ozone Data Save the subkey to directory DigiCORAIII: 1109-019 Figure 11 Saving Parameters VAISALA _______________________________________________________________________ 17...

  • Page 20: Importing Ozone-Oif92 And Parameters

    TECHNICAL NOTE _________________________________________________________________ Importing Ozone-OIF92 and Parameters Select Triggering. Right-click and select Import. 1109-026 Figure 12 Importing Ozone-OIF92 Select the Ozone-OIF92 file you saved earlier in the DigiCORAIII directory. The Ozone-OIF92 subkey will appear under the Triggering key and it replaces the old Ozone-OIF92 subkey. 18 __________________________________________________________________ M211299EN-B...
  • Page 21 Select the Parameters file you saved earlier in the DigiCORAIII directory. The Parameters subkey will appear under the Ozone- OIF92 key and it replaces the old Parameters subkey. You can now start simulating archived ozone data with the new sounding software. VAISALA _______________________________________________________________________ 19...
  • Page 22 *M211299EN*...
