Page 1: Air Conditioner
& CARE MANUAL READ AND SAVE THESE INSTRUCTIONS HEAVY DUTY AIR CONDITIONER MULTI-STEP SPEED ELECTRONIC CONTROLS P/N 309000855/03... -
Page 2: Warranty
Electrolux authorizes no one else to change or add to any of these obligations under this warranty. Any obligations for service and parts under this war- ranty must be performed by Frigidaire Consumer Services or an authorized Frigidaire servicer. -
Page 3: Table Of Contents
Model No. ______________________________________________ Serial No. _______________________________________________ Register Your Product The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to the Frigidaire Company. Warranty Product Registration Normal Sounds Important Safety Instructions Opeation of current Device 5-11... -
Page 4: Important Safety Instructions
If the air conditioner is to be installed in a window, you will probably want to clean both sides of the glass first. If the window is a triple-track type with a screen panel included, remove the screen completely before installation. -
Page 5: Electronic Control Operating Instructions
Air Conditioner Features ON/OFF ADJUSTS TEMP&TIMES SETS MODES REMOTE SENSING (On some AUTO TEMP REMOTE CONTROL Batter Size: AA WARRING: Do not Mix Old And New Batteries. Do Not Mix Alkaline, Standard (Carbon-Zinc). Or Rechargeable (Nichel-Cadmium) Batteries. TO TURN UNIT ON:... -
Page 6: To Operate On Fan Only
Air Conditioner Features (continued) TO CHANGE FAN SPEEDS: Temp/Timer Auto Clean Check Sleep Temp Filter Cool Temp/Timer Energy Saver Fan Only Remote Sensing Timer Mode A 2 Digit Display is used to indicate the fan speed setting, from 10 through 99. When the “SLOWER” button is pressed the motor speed will slow down at various intervals, down to a minimum setting of 10. - Page 7 Air Conditioner Features (continued) TO USE THE ENERGY SAVER FEATURE: Temp/Timer Auto Clean Check Sleep Temp Filter Cool Temp/Timer Energy Saver Fan Only Remote Sensing Timer Mode Note: In this mode, the fan will continue to run for another 3 minutes after the compressor shuts off. The fan then cycles on for 2 minutes at 10 minute intervals until the room temperature is above the set temperature, at which time the unit cooling system turns back on.
- Page 8 Air Conditioner Features (Continued) CHECK FILTER FEATURE: Note: This feature is a reminder to clean the Air Filter (See Care and Cleaning) for more efficient operation and cooling. The LED (light) will illuminate after 250 hours of operation. To reset after cleaning the filter, press the “Clean Filter”...
-
Page 9: Fault Codes
Auto Clean Temp Cool Temp/Timer Energy Saver Fan Only Timer Mode If the display reads “AS”, a sensor has failed. Contact your Authorized Frigidaire Service Center DO THIS: PRESS ON/OFF BUTTON YOU WILL SEE: Check Sleep Filter Remote Sensing Timer... -
Page 10: Additional Things You Should Know
º º Fresh Air Vent Control The Fresh Air Vent allows the air conditioner to: 1. Recalculate inside air-Vent Closed (see fig. 1) 2. Draw fresh air into the room-Vent Open (see Fig. 2) 3. Exchange air from the room and draws fresh air into the room-Vent and Exhaust open (see Fig. -
Page 11: Air Filter Cleaning
Or, instead of washing you may vacuum the filter clean. Cabinet Cleaning Be sure to unplug the air conditioner to prevent shock or fire hazard. The cabinet and front may be dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent. -
Page 12: Avoid Service Checklist
Room too cold Remote sensing deactivating Prematurely (some models). If These Solution Fail, Call 1-800-444-4944 For Frigidaire Service. Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workman- ship or materials in this appliance.
