Specifications - Behringer COMPOSER PRO MDX2200 Technical Specifications

Interactive 2-channel expander/gate/compressor/limiter of the reference class
Hide thumbs

Advertisement

SPECIFICATIONS

AUDIO INPUT
Connectors
Type
Impedance
Nominal Operating Level
Max. Input Level
CMRR
AUDIO OUTPUT
Connectors
Type
Impedance
Max. Output Level
SC INPUT
Connector
Type
Impedance
Max. Input Level
SC OUTPUT
Connector
Type
Impedance
Max. Output Level
SYSTEM SPECIFICATIONS
Bandwidth
Frequency Response
Noise
THD
IMD
Crosstalk
Stereo Coupling
EXPANDER/GATE SECTION
Type
Threshold
Ratio
Attack
Release
COMPRESSOR SECTION
Type
Threshold
Ratio
Threshold characteristics
Auto characteristics
Manual Attack Time
Manual Release Time
Auto Attack Time
Auto Release Time
Output
XLR and 1/4" jack
RF filtered, servo-balanced input
50 kOhm balanced, 25 kOhm unbalanced
+4 dBu/-10 dBV switchable
+21 dBu balanced and unbalanced
typ. 40 dB, >55 dB @ 1 kHz
XLR and 1/4" jack
electronically servo-balanced output stage (optional transformer-
balanced)
60 Ohms balanced, 30 Ohm unbalanced
+21 dBu, +20 dBm balanced and unbalanced
1/4" jack
RF-rejecting, DC de-coupled, unbalanced input
>10 kOhm
+24 dBu
1/4" jack
RF-rejecting, DC de-coupled, unbalanced output
2 kOhm
+21 dBu
20 Hz to 20 kHz, +0/-0.5 dB
0.35 Hz to 200 kHz, +0/-3 dB
> 95 dBu, unweighted, 22 Hz to 22 kHz
0.008 % typ. @ +4 dBu, 1 kHz, Gain 1
0.04 % typ. @ +20 dBu, 1 kHz, Gain 1
0.01 % typ. SMPTE
< -100 dB, 22 Hz to 22 kHz
true RMS detection
IRC (Interactive Ratio Control) Expander
variable (OFF to +15 dB)
variable (1:1 to 1:8)
<1 ms / 50 dB, program dependent
variable (SLOW: 100 ms / 1 dB, FAST: 100 ms / 100 dB)
IKA (Interactive Knee Adaption) Compressor
variable (-40 dB to +20 dB)
variable (1:1 to oo:1)
variable (Interactive or Hard Knee)
Wave Adaptive Compressor
variable (0.5 ms / 20 dB to 100 ms / 20 dB)
variable (0.05 ms / 20 dB to 5 s / 20 dB)
typ. 15 ms at 10 dB, 5 ms at 20 dB, 3 ms at 30 dB
program dependent, typ. 125 dB/s
variable (-20 to +20 dB)
3
