Technical Specifications - Baxi GA Combi & System Boiler Range Specifications

Technical specifications

Sales Code
Controls
Concealed User Controls
User adjustable DHW temperature
User adjustable CH temperature
LCD Control Panel Temp/Status/Fault Diagnosis Display
Performance
Heat Output CH
Heat Output DHW
Maximum DHW Flow Rate (Delta T @ 35
Minimum DHW Flow Rate Required
Minimum Operating DHW Pressure Required
SEDBUK 2005 Seasonal Efficiency NG/LPG
SEDBUK 2009 Seasonal Efficiency NG/LPG
NOx Class (5 being lowest)
NOx Emission
CO Emission
Gas
Gas Supply Pipe Size
NG & LPG (Propane) Compatible (single product)
Nominal Gas Inlet Pressure
Maximum Gas Rate (NG/Propane) after 10 mins
Electrical
Electrical Supply
Permanent Live Required
Electrical Cable Required
Power Consumption
External Fuse Rating
Boiler IP Rating
Mechanical & Hydraulic Connections
CH Flow/Return Pipe Size
DHW Flow/Inlet/PRV Size
Condensate Discharge Pipe Size
Installation
24 hr Pump Exercise
Pump Overrun
System Filling Loop
Integral System Pump
Integral 'Boiler Only' Frost Thermostat
Pre-plumb Jig Available
Stand off Bracket (Optional)
Installer Lift Weight
Flue Systems
Max Horizontal Ø60/100
Max Vertical Ø60/100
Max Horizontal Ø80/125
Max Vertical Ø80/125
Twin-pipe Horizontal Ø80/80
Twin-pipe Vertical Ø80/80
Plume Management Kit (Max length)
www.baxi.co.uk
402050-06 Baxi range guide.indd 11
Boiler only
Std. Flue
kW (Max)
kW (Min)
Output - kW (Max)
Max) l/min
o
l/min
bar
%
%
1 - 5
mg/kW/h
mg/kW/h
(mm)
NG/LPG (mbar)
m 3 /hr
Volts/Hz
(Core)
Watts
Amps
Approval Category
(mm)
(mm)
(mm)
Max (kg)
m
m
m
m
m
m
m
Duo-tec Duo-tec Duo-tec
Combi Combi Combi
24 GA 28 GA 33 GA
720117801 720118001 720118201
720598701 720598701 720598701
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
20 24 28
3.4 3.8 4.7
24 28 33
9.8 11.5 13.5
2 2 2
0.15 0.15 0.15
91.1/93.2 91.1/93.2 91.1/93.2
88.9/91.0 89.0/91.0 89.0/90.9
5 5 5
16.1 19.3 17
5.1 8 7.5
22 22 22
Yes Yes Yes
20/37 20/37 20/37
2.5/1.92 3.0/2.25 3.5/2.64
230V/50Hz 230V/50Hz 230V/50Hz
Yes Yes Yes
3 x 0.75 3 x 0.75 3 x 0.75
104 116 133
3 3 3
IPX5D IPX5D IPX5D
22 22 22
15 15 15
21.5 21.5 21.5
Yes Yes Yes
Yes Yes Yes
Standard Standard Standard
2 Speed 2 Speed 2 Speed
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
36 36 38
10 10 10
10 10 10
20 20 20
20 20 20
15 15 15
15 15 15
8 8 8
Duo-tec
Combi
40 GA
720118401
720598701
Yes
Yes
Yes
Yes
33
5.7
40
16.4
2
0.15
91.1/93.2
88.9/90.9
5
26.5
22.8
22
Yes
20/37
4.2/3.06
230V/50Hz
Yes
3 x 0.75
142
3
IPX5D
22
15
21.5
Yes
Yes
Standard
2 Speed
Yes
Yes
Yes
39
10
10
20
20
15
15
8
11
