Stinger Refrigerant Recovery Unit User Manual page 12

Rear View Components
Component
Power Switch
Two Circuit
Breakers
Connector for
optional 80%
tank full
shutoff cord
Storage
Pocket
Power Cord
12
When in the ON position, this switch starts the recovery
operation by turning ON the compressor.
Protects the STINGER from over current.
This optional accessory (Part Number 2090-0091)
connects to a DOT recovery cylinder's overfill sensor. It
automatically shuts the STINGER off when the recovery
cylinder reaches 80% of its liquid-fill limit.
This heavy-duty storage pocket is used to store the
Operation Manual, the Warranty Card and the original
invoice. These items should be kept with the unit at all
times.
230 VAC units have a male IEC 60320 type plug that
requires the use of a customer-supplied power-cord
adapter.
Description
2090-0217 Rev 6
