- Page 1 A1400-8 - Owners Manual Digital Amplifier...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 3 WELCOME Every member of our Axiom team, myself included, is pleased that you have decided on one of our products. We have all worked hard to bring the highest level of satisfaction to your audio experiences, and will continue to work hard to make every Axiom purchase a wise audio investment for you.
- Page 4 T2.5AL, 250V T20AL, 250V Caution - High Voltage Inside Mise en garde - Voltage élevé à l‘intérieur Step 2 Step 1...
- Page 5 A1400-8 ELECTRICAL CONNECTIONS Visit www.axiomaudio.com/manual_index.html for this Owner’ s Manual with live links to further helpful information Step 1: Set the voltage switch on the bottom of the A1400-8 to the appropriate voltage for your country. The voltage switch is preset at the factory for 115 volts (North America and Japan). For most of the rest of the world Step 7 the voltage switch will need to be changed to 230 volts. Damage will occur if you plug into a 230 volt line with the switch in the 115 position. Step 2: Insert the supplied power cord into your A1400-8 and place the amp on its feet.
-
Page 6: Speaker Wire
ESSENTIAL INCLUDES ADAPTOR These insert into the center of the XLR jacks to allow RCA inputs. Your A1400-8 comes with 8 of each style adaptor. AMPLIFIER ACCESSORIES RCA INTERCONNECT Rugged audio connector for low-loss connection between your Pre-Amp and A1400-8. RCA male jacks at both ends. BANANA PLUG BULK CABLE TERMINATED SPEAKER WIRE... - Page 7 SPECIFICATIONS A1400-8 FREQUENCY RESPONSE 4Ω 10 Hz to 20 kHz +0 dB, -0.5 dB SIGNAL TO NOISE RATIO >105 dB UNWEIGHTED TOTAL HARMONIC 1 kHz < 0.03% DISTORTION (THD+N) 20 kHz < 0.03% RISE TIME <8uS (500 W) DC OFFSET <0.2mVRMS GAIN 25.8 dB INPUT IMPEDANCE RCA 10K Ohms XLR 10K Ohms INPUT SENSITIVITY 1.50 VRMS OUTPUT VOLTAGE Peak to Peak 180 V RMS 53 V OUTPUT POWER EACH CHANNEL 8 Ohms 350 W <0.7% THD+N 4 Ohms 700 W <0.7% THD+N 2Ohms 1200W <0.7% THD+N...
- Page 8 Axiom Audio Head Office 2885 Highway 60 Siège Social Axiom Audio Dwight, ON Canada P0A 1H0 Toll Free (North America) 1-866-244-8796 Sans frais (Amérique du Nord) 1-888-249-9143 Worldwide • International 1-705-635-3090 Email • Courriel: info@axiomaudio.com www.axiomaudio.com Visit www.axiomaudio.com/manual_index.html for this Owner’s Manual with live links to further helpful information...
