IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
TECHNICAL SPECIFICATION MODEL Q-NEX5.4 Q-NEX10.4 Q-NEX14.4 Q-NEX20.4 Channels Total Output Power 5000 W 10000 W 14000 W 20000 W Output Power* (All ch driven/single ch) 2 ohms 4x1250 / 1x1250 W 4x2500 / 1x2500 W 4x3500 / 1x3500 W 4x5000 / 1x5000 W 2.67 ohms 4x1250 / 1x1700 W 4x2500 / 1x3300 W...
SETUP AND RACK MOUNTING To ensure proper air circulation the amplifiers must be installed as shown in the figures below. The dust filter on the front panel should be checked and cleaned periodically RECOMMENDED INSTALLATION ON 8U OPEN RACK FRONT REAR COLD AIR HOT AIR...
FRONT PANEL 1 - TOUCH DISPLAY This is an IPS display with capacitive touch panel that allows you to view and change the main parameters of the amplifier (see below for a detailed explanation). 2 - DIAL ENCODER/BUTTON Pressing and turning this dial allows you to change the parameters of the amplifier currently selected on the display. 3 - FRONT COOLING AIR VENT This is the opening through which air flows to cool the amplifier.
9 - TERMINATE BUTTON / LED This button allows you to terminate the last Q-NEX unit in a PRONET AX network: the LED lights up yellow when terminate button is pressed. See PRONET AX Network section below for detailed instructions.
10 - OUTPUT 1 - 4 These are the four SPEAKON connectors that allows to connect the four internal amplifiers to the speakers. Each SPEAKON has a different connection: SPEAKON amplifier channel standard bridge* CH1+ positive CH1- negative CH2+ positive CH2- negative CH2+ positive CH2- negative...
Q-NEX DSP OPERATIONS The PRONET AX software must be used to control the Q-NEX amplifiers' built-in CORE2 DSP. All features of the CORE2 DSP are described in the PRONET AX user manual (see the HELP menu), so only some peculiarities of the Q-NEX amplifiers architecture are explained in this manual.
1. Switch on all the amplifiers. 2. Connect all the amplifiers with the network cable. 3. In the SETTINGS page of each Q-NEX amplifier device set “ID ASSIGN” as “AUTO-ID”: a different ID will be assigned automatically to at each amplifier.
This column shows which page of the menu is active. To select the page, touch the screen or use the dial. The available pages are HOME (Axiom logo), ROUTING (folder), INPUT (faders), DEVICE (gear). This row shows the amplifier model and the name of the device assigned by Pronet AX. If the device is connected to a Pronet AX network and it is on-line, the row is red, if it's off-line the row is white.
Page 15
• Remove the output connection to check if there is a short circuit somewhere in the connected cable or the load. • Check if proper ventilation is ensured for the amplifier during its operation at all times. • Afterwards, if the warning notice persists, contact AXIOM service centre.
Here you can see the name of the OUTPUT channels specified by Pronet AX or recalling a Preset. Q-NEX matrix system allows you to assign any physical input from 1 to 4 to any of the four DSP INPUTS A to D, then assign the four DSP INPUTS to any POWER OUTPUT DSP from 1 to 4.
This example is a PA system for a typical large venue that has 4 inputs summed and routed to four zones with different systems, each with its own level, EQ, delay, and so on. INPUT PAGE This row shows the DSP INPUTS IN A, IN B, IN C, IN D. This row shows the current source input (1 to 4) assigned to each A to D DSP INPUTS.
SPEAKER PROTECTION SETTING If you use Q-NEX amplifiers to drive an AXIOM passive loudspeaker system, the PRESET supplied or downloaded from the website already contains all the protection parameters for the speakers, also if they are not visible by the user, so you need only to recall it using PRONET AX software and store it in the amplifier memory.
Page 19
The Peak Dynamic Control has several parameters to be set properly if you want that it operates as a power limiter: • Detect must be set as MID, this parameter set the speed of the limiter detector. • Ratio must be set as Limiter or at least at 20:1, all ratio below could be not efficient to protect a speaker. •...
