NJSR453EWWW - GE Hotpoint 7.0 Cu. Ft. Super Capacity Electric Dryer

Dryer Dimensions (in inches)

23-1/2
25-3/4
25-1/2*
8-1/2
Side View
Specification Revised 8/99
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
27
42
11-1/2
36
2
3-1/2
2-1/2

Rear View

Exhaust Options:

4-way via rear, right, left and bottom.

Circuit Requirements:

An individual, properly-grounded branch circuit, protected by a 30-amp circuit breaker or a time-
delay fuse, is required.

Electric Dryer Rating:

208/240V, 3-wire, 5600W, 60Hz, 30 Amp
Installation Information: For complete information, see installation instructions packed with
product for current dimensional data.
Best Performance
Maximum Length of 4"
Dia. Rigid Metal Duct
A
A
Exhaust Hood Type
4
Number
Cat. No.
B
of
WX8X59
90°
(Preferred)
Domestic
2-1/2
Turns
A
Dryer Models
4" Opening
0
90 ft.
1
60 ft.
Super & Extra-Large
2
45 ft.
Capacity Models
3
35 ft.
All Electric Dryers
4
25 ft.
0
45 ft.
Super & Extra-Large
1
35 ft.
Capacity Models
2
25 ft.
All Gas Dryers
3
15 ft.
0
60 ft.
1
52 ft.
Large Capacity
2
44 ft.
Electric and
3
32 ft.
Gas Dryers
4
28 ft.
Maximum Length of 4"
Dia. Flexible Metal Duct
Exhaust Hood Type
Cat. No.
WX8X59
B
B
(Preferred)
2-1/2"
A
2-1/2"
Opening
4" Opening
Opening
60 ft.
55 ft.
45 ft.
45 ft.
40 ft.
30 ft.
35 ft.
30 ft.
20 ft.
25 ft.
20 ft.
15 ft.
15 ft.
15 ft.
10 ft.
30 ft.
30 ft.
15 ft.
20 ft.
20 ft.
10 ft.
10 ft.
10 ft.
48 ft.
30 ft.
18 ft.
40 ft.
22 ft.
14 ft.
32 ft.
14 ft.
10 ft.
24 ft.
— ft.
16 ft.
— ft.
Listed by
Underwriters
Laboratories
R
