Oct/23/2006
MODEL MA-200
2-WAY REMOTE CONTROL MOTORCYCLE ALARM
INSTALLATION INSTRUCTIONS
MA200 IN REV.A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MA-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Autopage MA-200

  • Page 1 Oct/23/2006 MODEL MA-200 2-WAY REMOTE CONTROL MOTORCYCLE ALARM INSTALLATION INSTRUCTIONS MA200 IN REV.A...
  • Page 2 Oct/23/2006 INSTALLATION We recommend insulating all your soldered or crimped connections with heat shrink or electrical tape. We also recommend spraying silicone sealant on all your connections and plugs after they are connected and plugged in, spraying beforehand prevents good electrical connections. Keep wiring away from moving engine parts, exhaust pipes and high-tension cable.
  • Page 3 Oct/23/2006 WIRING DIAGRAM H7 2 Pin LED Indicator White H1 6 Pin Main 6 Pin White harness White H6 2 Pin Valet Switch Blue “Acc” “Start” H2 7 Pin Transmitter H5 4 Pin “On” 7 Pin White Mini Connector White Antenna Blue “Off”...
  • Page 4 Oct/23/2006 Many motorcycles and recreational motorcycles do not have front running lights. If the motorcycle does not have front running light, you may want to use the separate left and right turn signal indicators for flash purposes. Connect one of the two White wires to right line of turn indicator and connect the other one to the left line indicator.
  • Page 5 Oct/23/2006 This will become a 1 second pulse ground by activate button on transmitter for two seconds, the current capacity of this wire is 200 mA. This output can be programmed to provide the following type of output: 1 second pulse / latched / Latched with ignition / 30 / 60 / 90 seconds timer control. H2/7.
  • Page 6 Oct/23/2006 b. The system will advance to [2] LED flash, One chirp with a long chirp. (The factory default settings is always [1] LED flash, [1] chirp.) 4 Depress the transmitter button ‘A’ again to change the feature again. Simply keep re-depressing the transmitter button ‘A’...
  • Page 7 Oct/23/2006 30/ 60/ 90seconds timed output = A 30, 60, or 90-second timed output will send a signal for 30, 60, or 90 seconds, respectively, when the channel 3 / 4 transmitter button(s) are pressed. ALARM FEATURE “ ” PRORAMMING: 1.
  • Page 8 Oct/23/2006 6. Press and hold the buttons on the transmitter for 2 seconds. 2 long siren chirps will indicate the unit is ready to accept adjustments of the “warn-away” sensitivity. 7. Press and hold button on the transmitter for 2 seconds. [2] LED flash, [2] siren/horn chirps to indicates the unit is ready to accept the adjustments of the shock sensor.
