Audioplex STEALTH IR HW Installation Manual

Package:
Mounting:
Remotes:
Range:
Acceptance angle:
Power:
Your Stealth IR HW(tm) is a compact unit that is designed to act as a remote receiver and
processor of infrared signals. This sensor will receive signals from remote controllers and send
these signals to a remote repeater.
CAUTION: Take care to make sure that the Stealth IR HW(TM) installation is NOT IN THE
LINE OF SIGHT OR REFLECTION with the repeater. If radiation from the repeater is picked up
by this sensor, a feedback situation is created which will result in instability and unreliable
operation. Undesirable reflection can occur off of light colored walls, windows, mirrors, and even
shiny wood finishes! Follow the wiring diagram carefully(see back of this page for wiring
diagrams). NOTE: make all connections and check carefully prior to supplying power to the
unit! Please call if you have any questions about your installation.
Your AUDIOPLEX TECHNOLOGY(tm) Stealth IR HW(TM) is covered by a Lifetime warranty
against defects in workmanship and materials. Any defects will be remedied without charge for
labor or parts.
Damage incurred by shipping or accident is not considered to be a defect, and not covered
by this warranty. AUDIOPLEX TECHNOLOGY(tm) is not responsible for defective operation
caused by abuse or by modification or service by an unauthorized person or agency.
The unit must be properly installed and operated according to instructions for the
warranty to apply. Any necessary servicing must be done by AUDIOPLEX TECHNOLOGY(tm). The
products must be returned expences prepaid, with written authorization from the company. The
unit must be shipped with the proof of purchase and in the original carton and packing material to
avoid damage.
INSTALLATION MANUAL
TECHNOLOGY
STEALTH IR HW
Used as a remote receiver and processor

SPECIFICATIONS:

Includes: Stealth IR sensor (6 foot lead) and control unit.
Adhesive backing (control unit), adhesive backing (sensor)
Will handle almost all standard remote controllers (Note: does NOT work
with B & O equipment, which requires a proprietary confirmation talk-back
function).
110 feet indoors, 15 to 20 feet in direct sunlight.
+ or - 55 degrees off center axis.
12 VDC @ 500 mA

INSTALLATION:

WARRANTY

(Patent Pending)
TM
STEALTH HW 12/01
