- Page 1 QUALITY, RLIABILITY, & PURE BLISS MARINE SERIES FULL-RANGE AND COMPONENT SPEAKERS AMS50N / AMS60N / AMS69N / AMC620N OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
- Page 3 Other information can be located by using the table of contents. We at Audiobahn Inc. have worked very hard to make sure that all of the information in this manual is current, but, as we are constantly finding new ways to improve our product, this information is subject to change without notice.
- Page 5 Aluminum Mesh Grille Anti Rust Stainless Mounting Screws Lead Wire Insulated Tubing P.P. +Mica Brushed Cone with Rubber Surround AMS50N: 5.25” 2-Way Coaxial Marine SPeaker System 8 0z. Magnet (70 x 32 x 15mm) 25mm K.S.V. Voice Coil 13mm Horn Tweeter Power Handling: 80 RMS AMS60N: 6.5”...
- Page 6 AMS50N AMS60N AMS69N...
- Page 7 AMC620N INPUT WOOFER TWEETER The left two terminals are for wiring the input from an amplifier or source unit. It is advised to use an external crossover with the AMC620N. The center two terminals go to thw woofer portion of the system. The right two terminals are used to wire to the tweeter portion of the system.
- Page 8 Dimensions AMS50N 4 x 7mm 117.5mm 150.5mm 133mm 158mm 87.8mm 26mm 79.5mm...
- Page 9 Dimensions AMS60N 166mm 156.5mm 143mm 5.3 x 6mm 4.5mm diam. 175mm 105.7mm 26.2mm 92mm...
- Page 10 Dimensions AMS69N 242mm 275mm 222mm 169mm 203mm 149mm 5 x 9.5mm 129mm 30mm 110mm...
- Page 11 Dimensions AMC620C 166mm 156.5mm 143mm 5.3 x 6mm 4.5mm diam. 175mm 105.7mm 26.2mm 92mm...
