Chapter 1: Getting to know your FSG-3
GB
This chapter describes the lights and mechanical layout of the FSG-3.
1
1.1 FSG-3 connectors, LEDs and buttons
The FSG-3 Front panel
The front panel consists of:
1. Power on
2. Power on LED
3. LED ring
4. USB host port type A front 1
5. USB LED
6. USB host port type A front 2
7. USB unplug button
8. SATA LED
9. WAN LED
10. WLAN LED
8
1./2.
3.
4.
5.
6.
7.
8.
9.
10.
