Summary of Contents for Patton electronics 2039
- Page 1 USER MANUAL MODEL 2039 Parallel to Serial/ Serial to Parallel Interface Converter SALES OFFICE Part #07M2039-B (301) 975-1000 Doc. #102081U, Rev. C TECHNICAL SUPPORT Revised 1/23/08 C E R T I F I E D (301) 975-1007 An ISO-9001 http://www.patton.com...
-
Page 2: Radio And Tv Interference
However, there is no guarantee that interference will not occur in a particular installation. If the Model 2039 does cause interference to radio or television reception, which can be... - Page 3 NOTE: Packages received without an RMA number will not be accepted. Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Model 2039. Technical Support hours: 8AM to 5PM EST, Monday through Friday.
-
Page 4: General Information
RS-232C serial data to parallel data format and vice versa. Incorporating advanced microprocessor technology, the Model 2039 is able to automatically sense and select parallel and serial modes. The Model 2039 requires no AC power or batteries and supports serial data rates to 115.2 Kbps. -
Page 5: Configuration Switches
Technical Support at (301) 975-1007. 3.1 CONFIGURATION SWITCHES The Model 2039 uses a set of eight external DIP switches (see Figure 1) that allow configuration to a wide range of applications. Because all eight switches are in one externally accessible DIP switch package, there is no need to open the case for configuration. -
Page 6: Detailed Switch Settings
DIP SWITCH SUMMARY TABLE Position Function Factory Default Flow Control Hardware Enabled LED Indicator Data, Parity, Stop Bits 8B, NP, 1S Data, Parity, Stop Bits Data, Parity, Stop Bits Data Rate 38400 bps Data Rate Data Rate 3.2 DETAILED SWITCH SETTINGS This section provides detailed information about the function of each DIP switch and lists all possible settings. - Page 7 Stop Data Parity Switches 6 through 8: Frequency and Data Rate Switches 6 through 8 determine the frequency and data rate. The following chart shows the settings that may be used: Model 2039 Data Rate 1,200 2,400 4,800 9,600 19,200...
-
Page 8: Installation
4.0 INSTALLATION The Patton Model 2039 is very simple to install. Once you have configured the DIP switches, just plug it in like a normal cable and you're ready to go. Figure 3 illustrates the proper connections for the standard cables. If you have special-ordered a non-standard connector, your connections may be different. -
Page 9: Operation
"ON/OFF" switch. 5.1 LED STATUS MONITORS The Model 2039 features an easy-to-read status LED that glows red to indicate the condition of the transmission line. Figure 1 shows the location of the LED. The following chart describes the LED's various functions. - Page 10 APPENDIX A PATTON MODEL 2039 SPECIFICATIONS Interface: Async., RS-232C compatible Connectors: Serial, DB-9 F; parallel, Centronics 36 pin M Cables: Six foot integral cable Data Rates: 1.2 - 115.2 Kbps LED: LED displays status and operating condition Power Supply: None required; uses power from RS-232C...
- Page 11 APPENDIX B PATTON MODEL 2039 INTERFACE CONNECTIONS PARALLEL PORT CONNECTIONS Name Description Strobe Output; normally high, goes low to read data on power up Data bit 0 Output Data bit 1 Output Data bit 2 Output Data bit 3 Output...
- Page 12 APPENDIX C PATTON MODEL 2039 BLOCK DIAGRAM Copyright © Patton Electronics Company All Rights Reserved...
- Page 16 Dear Valued Customer, Thank you for purchasing Patton Electronics products! We do appreciate your business. I trust that you find this user manual helpful. We manufacture one of the widest selections of data communications products in the world including CSU/DSU's, network termination units, powered and self-powered short range modems, fiber optic modems, interface converters, baluns, electronic data switches, data-line surge protectors, multiplexers, transceivers, hubs, print servers and much more.
