Quick Start
Quick Reference Setup Guide
This quick reference guide is provided to help you set up your
CLUB-3800 system for the first time. It contains instructions
on setting up the products that are included in the CLUB-
3800. If you are connecting any additional gear that is not
included in the CLUB-3800, refer to the appropriate manuals
for detailed instructions.
Gathering Package Contents
The first step to putting together your new CLUB-3800 system is unpacking all of the necessary equipment. Remem-
ber to keep your manuals nearby when setting up, as you may need to reference them. The products listed below are
included in the CLUB-3800 system:
CDG-9000 PRO CD/CDG Player
• [1] Instruction Manual
DA-2200 PRO Digital Karaoke Mixer
• [1] Instruction Manual
VP-300 PRO 300W Professional Power Amplifier
• [1] Instruction Manual
VX-15 Vocal Speakers
• [2] VX-15 speakers
Mounting components into the RC-8
Follow these basic guidelines when mounting:
• Always screw in the mounting screws using an "X" forma-
tion.
• If possible, to keep the products cooler, leave some space in
between the components in the rack.
1
4
CLUB-3800
3
2
SS-88 Speaker Stands
• [2] SS-88 speaker stands
RC-8 Road Case
• [1] RC-8 road case
• [1] Rolling cart
• [2] MARK-38 microphones
• [1] Gooseneck DJ light
• [1] Double RCA to ¼" cable
• [2] MDP to ¼" cable
• Rack-mounting screws
Below is one way to configure your CLUB-3800:
On the web at www.vocopro.com
or call toll free 1-800-678-5348
CDG-9000 PRO CONTROLLER
CDG-9000 PRO PLAYER
DA-2200 PRO MIXER
VP-300 PRO AMPLIFIER
