Connecting Rover to a Device

You can use three methods to connect to Trane devices using LonTalk technology:
•
•
•

Connecting to a Zone Sensor

The zone temperature sensor must be connected to the LonTalk link that contains the devices you
want to configure.
To connect Rover to a zone temperature sensor:
1. Connect the supplied USB cable between the PC and the USB LonTalk adapter
2. Connect the USB cable adapter to the USB LonTalk adapter. The adapter should click easily into
3. Connect the RJ11 plug on the other end of the USB 2.0 cable adapter to the RJ11 jack on the zone
4. Test the communications link. Refer to
Figure 2. Connecting Rover to zone temperature sensor
EMTX-SVX01G-EN
Connect Rover to a zone temperature sensor communications jack that is connected to LonTalk
devices with Comm wire
Connect Rover to a LonTalk device using alligator clips
Connect Rover to a LonTalk device using the quick connect adapter
the card. If you have to use force, the adapter may be upside down.
temperature sensor.
Connecting Rover to a Device
"Verifying Network Communications, " p.
(Figure 2).
15.
