- Page 1 Owner’s Manual Model Number: PBQ-120-METRO Serial Number Model Number PBQ-120-METRO Part Number 6901480100 7210180100rev01...
- Page 2 PowerChef Table Top Features ® Welcome and Thank You Top grill, with no open flame or for purchasing a Dimplex combustion, heats up quickly, PowerChef Table Top Electric and never needs refueling! No ® Grill. gas or other fuel fumes will impart...
- Page 3 Additional appliances on the same circuit may exceed the current rating of the circuit breaker. Accessories For the complete line of electric BBQ accessories contact you authorized Dimplex dealer or visit us on the web at www.dimplexoutdoors.com.
-
Page 4: Table Of Contents
CONTENTS Important Instructions ....... Page 5 Model and Serial Number Information ..Page 7 Assembly ..........Page 8 Site Selection and Preparation ....Page 9 Operation ..........Page 10 Care and Cleaning........Page 11 Warranty ........... Page 13 Replacement Parts ........Page 15... -
Page 5: Important Instructions
Do not attempt to repair the appliance yourself. Contact your authorized service agent for installation of electrical replacement kit. 8. The use of non Dimplex accessory attachments is not recommended and may cause damage to the unit or injury. 9. Never let cord touch hot surfaces. -
Page 6: Save These Instructions
you must use an extension cord, it must be intended for outdoor use and have a rating of no less than 1875 Watts. Outdoor extension cords are marked with the suffix letters “W-A” and have a tag stating “Suitable for Use with Outdoor Appliances”. -
Page 7: Model And Serial Number Information
Model and Serial Number Information If you have any questions regarding this product please have the model and serial numbers available upon calling customer service or technical support. To locate the model and serial number labels see Figure 1 and 2 below. Record the model number, serial number, on the front cover of this manual and save for future reference. -
Page 8: Assembly
Assembly CAUTION: Bottom surface is hot when in use. Do not operate without legs installed, may cause personal injury or fire. Position leg as shown in Figure 2 and attach with the supplied hardware, using a Phillips screwdriver. Figure 2 Positioning Pegs (2) -
Page 9: Site Selection And Preparation
Site Selection and Preparation NOTE: A Ground Fault Interrupt (GFI) outdoor outlet or a circuit protected by a ground fault breaker with a rating of 15 Amps, 120 Volts is strongly recommended. A dedicated circuit is preferred but not essential in all cases. A dedicated circuit will be required if, after installation, the circuit breaker trips or the fuse blows on a regular basis when the electric grill is operating. -
Page 10: Operation
Operation The Control Dial for the grill uses a simple method of operation. Pull the dial up to turn the grill on, and push the dial back down to turn the grill off. The red Indicator Light (Figure 4) will illuminate and remain on until the Control Dial is pushed in to turn off the grill, regardless of what power level the Control Dial is set at. -
Page 11: Care And Cleaning
Care and Cleaning WARNING: Unplug the electric grill from outlet when not in use or before cleaning. Do not clean this product with high pressure water spray. Store the electric grill indoors when not in use. Drip Tray CAUTION: Allow the grill to cool before attempting to clean the Drip Tray. - Page 12 Cooking Grid To keep your electric grill operating at optimal performance Dimplex recommends that you clean the cooking grid after each use. The cooking grid is permanently mounted into the body of the electric grill and cannot be removed.
-
Page 13: Warranty
Dimplex will not be responsible for, and the limited warranty shall not include, any expense incurred for installation, removal or repair of the product or part (or any replacement product or part) or transportation costs. - Page 14 Dimplex will, at it’s sole discretion, choose to replace such defective product or part, without charge. If Dimplex is unable to replace such product or part, or if Dimplex at it’s sole discretion deems the replacement not be commercially practical or cannot be completed on a timely basis, Dimplex may, in lieu of replacement, choose to refund the purchase price for such product or part.
-
Page 15: Replacement Parts
Bumpers (2)..... .8501400100RP Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 1-888-346-7539 www.dimplex.com © 2010 Dimplex North America Limited Approved for use in the United States and Canada Printed in China...
