Volvo S60 Wiring Diagram page 200

Component illustrations
10/17 - 10/47
10/17 Lamp housing, rear right
10/18 Lamp housing, rear left
10/19 Auxiliary brake light
10/29 Glove compartment lighting
10/42 Rear right running/parking light
A B
2
1 1 3
3 4 6
4
10-17_97
A B
2
1 1 3
3 4 6
4
10-18_97
1 5
10-19_97
2
1
10-29_97
10-42_97
TP 3997202 S60/S60R 2007
10/43 Right brake light
10/44 Right-hand tail light lamp 1
10/45 Right-hand tail light lamp 2
10/46 Fog light, rear right
10/47 Right-hand rear direction indicator
10-43_97
10-44_97
10-45_97
10-46_97
10-47_97
200
