VOLVO S60
Quick guide
WElCOME TO THE GlOBAl FAMIlY OF vOlvO
OWNERS!
Getting to know your new vehicle is an exciting experience.
This Quick Guide provides a brief overview of the most common features and
functions in your Volvo.
However, for the most up-to-date and detailed descriptions and instructions,
as well as important warnings and other information not included in this
folder, please refer to your Owner's Manual.
An asterisk (*) indicates optional equipment.
For additional information, contact Customer Service:
U.S.A.: 1-800-458-1552 www.volvocars.us
Canada: 1-800-663-8255 www.volvocanada.com
Advertisement
Table of Contents
Related Manuals for Volvo S60
Summary of Contents for Volvo S60
-
Page 1: Quick Guide
VOLVO S60 Quick guide WElCOME TO THE GlOBAl FAMIlY OF vOlvO OWNERS! Getting to know your new vehicle is an exciting experience. This Quick Guide provides a brief overview of the most common features and functions in your Volvo. However, for the most up-to-date and detailed descriptions and instructions, as well as important warnings and other information not included in this folder, please refer to your Owner’s Manual. -
Page 2: Starting The Engine
REMOTE KEY WITH PCC* – PERSONAl CAR COMMuNICATOR Locks the doors and trunk and arms the alarm Unlocks the doors and trunk, and dis- arms the alarm Trunk (press once to unlock; press twice to open trunk slightly). Approach lighting illuminates lights in door mirrors, cabin, footwells, license plates. Turn signals and parking lights illuminate. “Panic” alarm. – Press and hold to sound the alarm. Turn off alarm with unlock button. Information about the vehicle can be gathered within a range of 300 ft. (100 m). PCC* – Press the button and wait for 7 sec- Green light: vehicle is locked. onds. Yellow light: vehicle is unlocked. If the vehicle is out of range when the Red light: alarm has been triggered. button is pressed, the most recently stored status information will be shown. Alternatively flashing red lights: the alarm The accessory inclination and movement alarm sensors was triggered less than 5 minutes ago. can be turned off. See the “Alarm” section of your owner’s manual for information. Automatic relock occurs if no door/trunk is opened within 2 minutes after unlock STARTING THE ENGINE... -
Page 3: Blind Spot Information System (Blis)
SWITCHING OFF THE ENGINE AND RE- BlIND SPOT INFORMATION SYSTEM (BlIS)* MOvING THE REMOTE KEY If the BLIS indicator lights illuminate even when Park the vehicle and press the START/STOP ENGINE there are no vehicles in the blind area, this may button to switch off the be due to light reflected from a wet road surface, engine. the vehicle’s own shadow against a large, light, Pull the remote key out of smooth surface, or sunlight directly in the camera the ignition slot. when the sun is low on the horizon. If there is a fault with the system, Blind spot syst. Service required will be displayed. IGNITION MODES 0 AND I To access the following ignition modes: The Modes Active functions brake pedal must not be depressed. -
Page 4: Cd/Dvd Player
WINDSHIElD WIPERS AND RAIN SENSOR* Single wiper sweep. Intermittent wipers. Turn (2) to adjust. Normal wiper speed. High wiper speed. Windshield/headlight washers. Displayed when the rain sensor is Rain sensor On/Off with the lever in the 0 active. position. Turn to adjust intermittent wiper speed or rain sensor sensitivity where applicable. INFOTAINMENT SYSTEM CD/DvD PlAYER Turn to adjust volume. Press to eject a disc. Press for ON/OFF. Turn to change CD tracks. Press to choose AM, FM1, FM2, SIRIuS1*, SIRIuS2*. Change CD tracks with the left/right arrow keys. Press to choose DISC, iPod *, AuX/ uSB ® Media BT*. AuX AND uSB Press for sound settings such as Bass, Tre- An iPod or MP3 player can be connected to ®B ble or Surround* – Turn TuNE (6) to adjust. -
Page 5: Electronic Climate Control-Ecc
ElECTRONIC ClIMATE CONTROl—ECC AuTOMATIC CONTROl In AuTO mode, ECC controls all functions automatically and makes driving more pleasant with optimal air quality. Turn the control to the desired temperature on the left/right sides of the cabin. The set temperature is shown in the display. Press to automatically control the temperature and other functions. MANuAl CONTROl Heated driver/front passenger seat*. Max. defroster. Directs maximum air flow to the windshield and front side windows. Blower speed. Air distribution. Heated rear window and door mirrors. Recirculation. Air conditioning Off/On to cool the cabin and defog the windows. STORAGE SPACES, 12-vOlT SOCKETS & AuX/uSB CONNECTOR AuX/uSB can be used to connect e.g., an mp3 The 12-volt sockets in the cabin function in igni- tion modes I or II. player to the vehicle’s infotainment system. The 12-volt socket* in the trunk always func- CAuTION tions. Using the optional 12-volt socket in the trunk with the engine switched off will drain the battery. -
Page 6: Steering Wheel Adjustment
ODOMETER AND TRIP COMPuTER Low fuel level indicator When the symbol illuminates, refuel as soon as possible. The display shows two separate trip odome- ters, T1 & T2. Fuel gauge The fuel filler door is on the right, as indica- Press to display or erase a message. ted by the arrow. Turn to show trip computer information Trip computer display. Select function with alternatives. (8). A short press resets the current function. Clock: Adjust with (6). A long press resets all functions. Multi-function control Turn the control clockwise or counterclock- NOTE wise to set the clock. The display text Miles to empty tank is an A short press toggles between T1 & T2. approximation, based on recent average fuel A long press resets the displayed odometer. consumption. STEERING WHEEl ADjuSTMENT BluETOOTH Make the cell phone discoverable/visible. Press the TEl button on the center console control panel briefly. Select “Add phone” in the display. Select the cell phone to be connected. -
Page 7: Driver Support Systems
lIGHTING PANEl Display & instrument panel lighting. Rear fog light (driver’s side only). Automatic headlights. High beam flash only. Parking lights Headlights: turn off when ignition is switched off, high/low beams. Open the fuel filler door. Press once to unlock the trunk, press twice to pop open the trunk slightly. High beam flash Toggle between high/low beams. Home safe lighting. DRIvER SuPPORT SYSTEMS WARNING The driver is always responsible for keeping a safe distance to the vehicle ahead. City Safety™ is a supplemental aid to the dri- ver. It can never replace the driver’s attention to traffic conditions or his/her responsibility for operating the vehicle in a safe manner. City Safety™ may never be used instead of the driver applying the brakes. City Safety™ does not function in all driving situations or in all traffic, weather or road conditions. City Safety™ and Collision Warning with Full CITY SAFETY™ AND COllISION WARNING Auto-brake do not function in all traffic, light, weather and road conditions and can only de- WITH Full AuTO-BRAKE* tect pedestrians with clear body contours and... -
Page 8: Car Care
EMERGENCY BRAKE ASSIST (EBA) ADjuSTING THE FRONT SEAT EBA is designed to provide full brake effect im- mediately in the event of sudden, hard braking. When EBA is activated, the brake pedal will go down more than usual. – Press and hold the brake pedal for as long as necessary – there will be no braking effect if the pedal is released. CAR CARE Hand washing is gentler on the paint than an automatic car wash. Since the paint on a new vehicle may take several months to harden Lumbar support. completely, we recommend washing the vehicle by hand during this period. Use clean water, a Backrest tilt. suitable car washing detergent and a sponge. Raise/lower the seat. Keep in mind that dirt or grit on the sponge can Raise/lower the front edge of the seat scratch the paint. cushion. Forward/rearward. Folding down the passenger’s seat back- rest. See the Owner’s Manual for more information. ElECTRIC PARKING BRAKE Setting – Press the button. The light flashes until the parking brake is fully applied, then glows continuously.
