PREVOST GKN AXLES LIMITED KIRKSTALL DIVISION Service Manual

PREVOST GKN AXLES LIMITED KIRKSTALL DIVISION Service Manual

For axle type s82
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
1. DESCRIPTION......................................................................................................................................... 16-3
2. AIR SPRING ............................................................................................................................................ 16-4
2.1
Inspection........................................................................................................................................ 16-4
2.2
Removal.......................................................................................................................................... 16-4
2.3
Installation....................................................................................................................................... 16-4
3. SHOCK ABSORBER ............................................................................................................................... 16-5
3.1
Inspection........................................................................................................................................ 16-5
3.2
Removal.......................................................................................................................................... 16-5
3.3
Installation....................................................................................................................................... 16-6
4. RADIUS ROD........................................................................................................................................... 16-6
4.1
Inspection........................................................................................................................................ 16-6
4.2
Removal.......................................................................................................................................... 16-7
4.3
Bushing Removal ........................................................................................................................... 16-7
4.4
Bushing Installation......................................................................................................................... 16-7
4.5
Installation....................................................................................................................................... 16-7
5.1
Removal.......................................................................................................................................... 16-8
5.2
Installation....................................................................................................................................... 16-8
6. SUSPENSION AIR SYSTEM .................................................................................................................. 16-9
6.1
Description...................................................................................................................................... 16-9
6.2
Inspection........................................................................................................................................ 16-9
6.3
Air Line Test.................................................................................................................................... 16-9
6.4
Air Tank Maintenance..................................................................................................................... 16-9
7. SUSPENSION HEIGHT ADJUSTMENT................................................................................................. 16-9
8. HEIGHT CONTROL VALVE.................................................................................................................. 16-10
8.1
Operation ...................................................................................................................................... 16-10
8.1.1 Loading Position ................................................................................................................ 16-10
8.1.2 Neutral Position.................................................................................................................. 16-10
8.1.3 Unloading Position............................................................................................................. 16-10
8.2
Maintenance ................................................................................................................................. 16-10
8.2.1 Removal and Installation ................................................................................................... 16-11
8.2.2 Air Leakage Test................................................................................................................ 16-11
9. FRONT KNEELING AND HI-BUOY SYSTEM (IF APPLICABLE)........................................................ 16-12
9.1
Principles of Operation ................................................................................................................. 16-12
9.2
Maintenance ................................................................................................................................. 16-12
9.3
Keeling Sense Switch................................................................................................................... 16-13
9.4
Bellows Control and Exhaust Solenoid Valves ............................................................................ 16-13
9.4.1 Removal and Installation ................................................................................................... 16-13
10. HI-BUOY SYSTEM ................................................................................................................................ 16-13
10.1 Principles of Operation ................................................................................................................. 16-13
SECTION 16: SUSPENSION
