Operating instructions
for the system user
Compact heat pumps with electric drive
VITOCAL 222-G
VITOCAL 242-G
VITOCAL 333-G
VITOCAL 333-G NC
VITOCAL 343-G
Please keep safe.
5592 628 GB
8/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VITOCAL 222-G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Viessmann VITOCAL 222-G

  • Page 1 VIESMANN Operating instructions for the system user Compact heat pumps with electric drive VITOCAL 222-G VITOCAL 242-G VITOCAL 333-G VITOCAL 333-G NC VITOCAL 343-G Please keep safe. 5592 628 GB 8/2009...
  • Page 2: Safety Instructions

    Safety instructions For your safety Please follow these safety instructions closely to prevent accidents and mate- rial losses. Safety instructions explained Danger Incorrect work on the system can Danger lead to life-threatening acci- This symbol warns against the dents. risk of injury. Work on electrical equipment must only be carried out by a Please note...
  • Page 3 Safety instructions For your safety (cont.) Auxiliary components, spare and wearing parts Please note Components that are not tested with the system may cause sys- tem damage, or may affect its functions. Installation or replacement work must only be carried out by quali- fied personnel.
  • Page 4: Table Of Contents

    Index Index Introductory information Device description....................Commissioning..................... Your system is preset at the factory..............Terminology......................Energy saving tips....................Operation Controls........................ 10 Menu........................11 How to use the controls..................12 Start-up/shutdown Starting the heat pump..................15 Stopping the heat pump..................15 ■...
  • Page 5 Index Index (cont.) Further adjustments Setting the display brightness................37 Setting the display contrast.................. 37 Entering designations for the heating circuits............37 Setting the time and date..................38 Language selection....................38 Selecting a temperature unit (°C/°F)..............38 Restoring factory settings..................39 Scanning Scanning information....................
  • Page 6: Device Description

    Introductory information Device description The Vitocal 222-G/242-G/333-G/343-G All connected components are operated are brine/water heat pumps with integral and controlled via the integral heat pump DHW cylinder. Solar collectors can be control unit Vitotronic 200, type WO1A connected to the Vitocal 242-G and 343- with plain text menu prompts.
  • Page 7: Commissioning

    Introductory information Commissioning The commissioning and matching up of the heat pump control unit to local con- ditions and to the structural characteris- tics of the building, plus the instruction of the user in operating the system, must be carried out by your heating contrac- tor.
  • Page 8: Terminology

    Introductory information Terminology To provide you with a better understand- ing of the functions of your heat pump control unit, the appendix contains the chapter "Terminology" (see page 51). Energy saving tips ■ Only activate the DHW circulation pump for when DHW is drawn off reg- ularly.
  • Page 9 Introductory information Energy saving tips (cont.) Further recommendations: ■ Correct ventilation/airing. Briefly open windows B fully and at the same time close thermostatic radi- ator valves C (if no domestic ventila- tion system is installed). ■ Close roller shutters (if installed) at dusk.
  • Page 10: Controls

    Operation Controls You can change any settings on your Note heat pump centrally at the programming The programming unit can be placed in unit of the heat pump control unit. a wall mounting base. This is available If remote control units are installed in as an accessory.
  • Page 11: Menu

    Operation Menu You have two control levels available, the "Standard menu" and the "Extended menu". Standard menu Flow temperature 40°C Heating/cooling Solar energy Information Select with In the "Standard menu", you can adjust ■ Selecting manual mode and scan the settings used most fre- ■...
  • Page 12: How To Use The Controls

    Operation Menu (cont.) Extended menu Menu Heating/cooling System Information Select with In the "Extended menu", you can adjust You call up the "Extended menu" as fol- and scan the settings from the control lows: unit's range of functions used less fre- ■...
  • Page 13 Operation How to use the controls (cont.) 40 °C Flow temperature Heating/cooling Solar energy Information Select with A Dialogue line The selected menu option is highlighted The following example shows the setting white. procedure with the possible dialogue The dialogue line then shows the neces- lines.
  • Page 14 Operation How to use the controls (cont.) Flow temperature 40°C Heating/cooling Solar energy Information Select with Heating circuit 1 Select heating circ Ù Ú Ù Ú Ù Ú Set room temp. Ú 20°C Heating program Heating circuit 2 ß Party mode Economy mode Select with Was selected...
  • Page 15: Starting The Heat Pump

    Start-up/shutdown Starting the heat pump Flow temperature 40 °C Heating/cooling Solar energy Information Select with A ON/OFF switch 1. Switch ON the power supply, e.g. at 2. Switch ON the system ON/OFF a separate MCB/fuse or a main iso- switch" ". lator.
  • Page 16: Without Frost Protection Monitoring (Shutting Down The System)

    Start-up/shutdown Stopping the heat pump (cont.) Note Standard menu − 20 °C, the 1. "Heating" or "Heating/cooling" At temperatures below 2. Select a heating/cooling circuit or the frost protection of the heat pump, the separate cooling circuit (see DHW cylinder and the heating water page 18).
  • Page 17: Required Settings (Heating/Cooling)

    Central heating/cooling Central heating/cooling Central heating Cooling via a separate cooling circuit ■ Central heating is only activated if the outside temperature falls below the ■ Cooling with a separate cooling circuit, heating limit. The heating limit can be e.g. chilled ceiling or fan convector set by your local heating contractor.
  • Page 18: Selecting The Heating/Cooling Circuit

    Central heating/cooling Selecting the heating/cooling circuit Central heating can be split over several Example: heating circuits (heating circuit 1, 2 or 3). ■ "Heating circuit 1" is the heating cir- Cooling results either through one of cuit for the rooms occupied by you. these heating circuits or via a separate ■...
  • Page 19: Enabling Electric Heater For Central Heating

    Central heating/cooling Setting the room temperature (cont.) Setting the room temperature for 4. "Red. Set room temp." reduced heating mode (night set- 5. Set the required value. back) The room will be heated to this temper- Factory setting: 16 °C ature, ■...
  • Page 20: Setting The Time Program For Heating/Cooling

    Central heating/cooling Setting the time program for heating/cooling Note 7. Set the start and end points for the No time program can be set for any sep- relevant time phase. The length of the arate cooling circuit. white bar inside the time diagram is matched accordingly.
  • Page 21 Central heating/cooling Setting the time program for heating/cooling (cont.) § Heating/cooling Mo-Su Heating/cooling Mo-Su 8 10 12 14 16 18 20 22 24 ? - -:- - - -:- - 8 10 12 14 16 18 20 22 24 § - -:- - - - -:- - ! 00:00 - 08:30 u Reduc.
  • Page 22: Change The Heating Curve

    Central heating/cooling Setting the time program for heating/cooling (cont.) "Fixed val." Factory settings: ■ Max. flow temperature for heat- Central heating is implemented, inde- ing: 60 °C pendent of the outside temperature, with ■ Min. flow temperature for cooling: the maximum permissible flow tempera- 10 °C ture;...
  • Page 23: Stopping The Central Heating/Cooling

    Central heating/cooling Change the heating curve (cont.) Note Setting the slope or level of the heating curve too high or too low will not result in damage to your heat pump or your heat- ing system. Stopping the central heating/cooling Standard menu 1.
  • Page 24: Comfort And Energy Saving Functions

    Comfort and energy saving functions Comfort and energy saving functions Comfort function "Party mode" selection With this function, you can change the Party mode room temperature of a heating/cooling circuit for a few hours, e.g. if guests stay a little longer in the evening. You do not 20 °C have to change any existing control set- tings.
  • Page 25 Comfort and energy saving functions Comfort and energy saving functions (cont.) Energy savings function "Economy mode" selection To save energy, you can reduce the Ending economy mode room temperature in standard heating mode, for example, if you leave the ■ Automatically when the system house for a few hours.
  • Page 26 Comfort and energy saving functions Comfort and energy saving functions (cont.) ■ Operating program "Only DHW": Only frost protection for the heat pump, DHW cylinder and heating water buffer cylinder (if installed) is enabled for all heating circuits. Extended menu: 2.
  • Page 27: Setting The Dhw Temperatures

    DHW heating Required settings (DHW heating) If you want DHW heating, check the fol- ■ Have you set the required time pro- lowing points: gram? ■ Have you set the required DHW tem- For settings, see page 29. perature? For settings, see page 27. ■...
  • Page 28: Setting The Operating Program For Dhw Heating

    DHW heating Enabling electric heater for DHW heating (cont.) Note To prevent the instantaneous heating water heater from being started auto- matically to boost DHW heating, you can disable it at any time. Setting the operating program for DHW heating Standard menu Note 1.
  • Page 29: Setting The Time Program For Dhw Heating

    DHW heating Setting the time program for DHW heating ■ The time program for DHW heating is 6. Set the start and end points for the made up of time phases. Set an oper- relevant time phase. The length of the ating status for each time phase white bar inside the time diagram is ("Top", "Normal", "Temp.
  • Page 30: Dhw Heating

    DHW heating Setting the time program for DHW heating (cont.) Example: "Normal" You want to set the same time program for every day except Monday: The entire volume of the DHW cylinder Select the period "Monday–Sunday" is heated to the standard DHW temper- and set the time program.
  • Page 31: Setting The Time Program For Dhw Circulation Pump

    DHW heating Setting the time program for DHW heating (cont.) Stop optimisation Standard menu 1. "DHW" The stop optimisation ensures that the 2. "1 x DHW heating" DHW cylinder is always fully heated at the end of the time phase with the oper- Note ating status "Normal".
  • Page 32 DHW heating Setting the time program for DHW circulation… (cont.) At the factory, no time phases for the Example: DHW circulation pump are set, i.e. the ■ Time program for Monday ("Mo-Su") DHW circulation pump is switched off. ■ Time phase !: ■...
  • Page 33: Switching Off Dhw Heating

    DHW heating Setting the time program for DHW circulation… (cont.) Deleting a time phase "5/25 cyc." ■ Set the time for the end point to the The DHW circulation pump starts twice same time that was set for the start per hour for 5 min (pause duration 25 point.
  • Page 34 DHW heating Switching off DHW heating (cont.) You do not want to heat DHW, but you do want to heat or cool the rooms. Standard menu 1. "Heating" or "Heating/cooling" 2. Where appropriate, select a heating/ cooling circuit or the separate cooling circuit.
  • Page 35: Setting A Time Program For The Heating Water Buffer Cylinder

    Heating water buffer cylinder Setting a time program for the heating water buffer cylinder ■ The time program for the heating water 6. Set the start and end points for the buffer cylinder is made up of time pha- relevant time phase. The length of the ses.
  • Page 36: Heating Water Buffer Cylinder

    Heating water buffer cylinder Setting a time program for the heating water… (cont.) Example: "Normal" You want to set the same time program for every day except Monday: The entire volume of the heating water Select the period "Monday–Sunday" buffer cylinder is heated to the highest and set the time program.
  • Page 37: Setting The Display Brightness

    Further adjustments Setting the display brightness You want the texts in the menu to be 3. "Brightness" more clearly legible. Change the bright- 4. "Operation" or "Screensaver" ness for "Operation". 5. Set the required brightness. You can also alter the screensaver brightness.
  • Page 38: Setting The Time And Date

    Further adjustments Entering designations for the heating circuits (cont.) The menu shows "Apartment" for Heat- Heating circuit 2 ing circuit 2. Apartment Apartment Apartment Ù Ú Set room temp. 22 °C Adopted Heating program ß Party mode Economy mode Select with Setting the time and date The time and date are factory-set.
  • Page 39: Restoring Factory Settings

    Further adjustments Restoring factory settings You can restore all modified factory set- 3. "Standard setting" tings for each heating or cooling circuit, 4. "Electric heater" the DHW heating and other system set- tings separately. The following settings are reset: ■ Instantaneous heating water heater is System settings enabled for central heating Extended menu...
  • Page 40: Scanning Information

    Scanning Scanning information Subject to the connected components Note and settings made, you can scan current The designation is displayed if heating/ temperatures and settings, time pro- cooling circuits have been designated grams and operating states. (see page 37). You can scan information in the "Stand- ard menu"...
  • Page 41: Scanning Messages

    Scanning Scanning information (cont.) ■ Average brine temperature on entry Boiler log into the heat pump "T.in" CW T.in T.out HP1 ■ Average brine temperature on exiting the heat pump "T.out" ■ Heat pump hours run ("heat pump") "HP1" ■ "HP2": no function ■...
  • Page 42 Scanning Scanning messages (cont.) Pressing ? provides you with the fol- Note lowing information regarding the ■ If you have connected up signalling selected message: equipment (e.g. an alarm) for fault ■ Date and time when the message messages, this is deactivated when occurred for the first time.
  • Page 43: Manual Mode

    Manual mode Manual mode In manual mode, central heating and DHW heating are implemented inde- pendently of the time programs: ■ Unregulated heating with a set flow temperature of 45 °C. ■ DHW heating with "Set temperature 2" (see page 27). ■...
  • Page 44: What To Do If Rooms Are Too Cold

    What to do if... Rooms are too cold Cause Remedy The heat pump is switched OFF. ■ Switch the ON/OFF switch " " ON (see figure on page 15). ■ Switch ON the mains isolator, if instal- led (outside the boiler room). ■...
  • Page 45: There Is No Hot Water

    What to do if... There is no hot water Cause Remedy The heat pump is OFF. ■ Switch the ON/OFF switch " " (see page 15) ON. ■ Switch ON the mains isolator, if instal- led (outside the boiler room). ■...
  • Page 46: Power-Off C5" Is Displayed

    What to do if... "Power-OFF C5" is displayed Cause Remedy This message is displayed whilst the No measures required. power supply is blocked by the power The heat pump restarts automatically in supply utility. accordance with the selected operating program as soon as the power supply util- ity restores the power supply.
  • Page 47: Cleaning

    Maintenance Repairs Cleaning All equipment can be cleaned with a commercially available domestic clean- ing agent (non-scouring). Inspection and maintenance The inspection and maintenance of a heating system is specified by the Energy Sav- ing Order [EnEV - Germany] and the DIN 4755, DIN 1988-8 and EN 806 stand- ards.
  • Page 48: Menu Overview

    Appendix Menu overview Standard menu (see page 11) Standard menu Help Heating Heating/cooling Solar energy Manual mode Information Set room temp. Outside temperature Heating program Compressor Party mode Heating circuit 1 HC1 Economy mode Act room temp HC1 Heating circ pump HC1 Heating circuit 2 HC2 Set DHW temp Act room temp HC2...
  • Page 49: Extended Menu

    Appendix Menu overview (cont.) Extended menu (see page 12) Extended menu Heating Heating/cooling System Information Settings Time prog. Buffer cylinder Set room temperature Heating with electro Red. Set room temp. Heating program Time / Date Party mode Language Economy mode Contrast Time prog.
  • Page 50 Appendix Menu overview (cont.) Extended menu Heating Heating/cooling System Information Settings System Heating circuit 1 Outside temperature Heating circuit 2 Mixed flow temp Heating circuit 3 Operating status system Cooling circuit SKK Heating season Cooling period Solar Buffer cylinder Heat pump Operating status buffer cyl.
  • Page 51: Terminology

    Appendix Terminology Setback mode (reduced heating Note mode) No heating program is available for cen- tral heating without DHW heating. If you See "Reduced heating mode". want central heating, hot water is gener- ally also required. Standby mode However, if you just want central heating, select the operating program "Heating Central heating/cooling and DHW heat- and DHW"...
  • Page 52 Appendix Terminology (cont.) Heating/cooling curve In order to guarantee sufficient heat at any outside temperature, the conditions Heating and cooling curves illustrate the of your building and your heating system relationship between the outside tem- must be taken into consideration. For perature, room temperature (set value) this you can adapt the heating curve (see and the (heating circuit) flow tempera-...
  • Page 53 Appendix Terminology (cont.) Factory-set, the slope = 0.6 and the level = 0. Outside temperature in °C A Changing the slope: C Changing the standard room tem- The steepness of the heating curve perature (set value): changes. The heating curves are offset along B Changing the level: the axis "Set room temperature".
  • Page 54 Appendix Terminology (cont.) Heating/cooling circuits and separate Actual temperature cooling circuit Current temperature at the time of the ■ Heating circuit scan; e.g. actual DHW temperature. A heating circuit is a sealed circuit between the heat pump and consum- Mixer ers (radiators), in which the heating water circulates.
  • Page 55 Appendix Terminology (cont.) Room temperature-dependent heat- Secondary pump ing or cooling mode The secondary pump transports the With room temperature-dependent oper- heating water from the heat pump into ation a room will be heated or cooled the heating system and, in heating sys- until the selected set room temperature tems with heating water buffer cylinder, has been reached.
  • Page 56 Appendix Terminology (cont.) Weather-compensated heating or cooling mode In weather-compensated mode, the flow temperature is controlled subject to the outside temperature. This means that no unnecessary heat or cooling capacity is generated to heat or cool the rooms to the set room temperature you selected. The outside temperature is captured and transferred to the heat pump control unit by a sensor fitted outside the building.
  • Page 57: Keyword Index

    Keyword index Keyword index Cooling mode Activating the holiday program...25 ■ standard..........54 Actual temperature......54 Cooling operation Average brine temperature....41 ■ standard..........18 Cooling settings ■ reset..........39 Brine temperature......41 Cursor keys........10 Cylinder primary pump.......55 Central cooling ■ Operating program......19 Daily log..........40 ■ Required settings......17 Date..........7, 16 ■...
  • Page 58 Keyword index Keyword index (cont.) Display ■ Setting the contrast......37 Glossary..........51 Display illumination ■ Setting the brightness.....37 Heat demand peaks......6 Heating Economy mode......8, 25 ■ Operating status......21 Electric heater settings Heating and DHW........7 ■ reset..........39 Heating circuit........54 Enable Heating circuit designation....37 ■...
  • Page 59 Keyword index Keyword index (cont.) Information No hot water........45 ■ Solar thermal system......40 Note Inspection...........47 ■ acknowledge........41 Instantaneous heating water ■ calling up........42 heater..........6, 16 ■ Power-OFF C5......42, 46 ■ for central heating......19 ■ scan..........41 ■ for DHW heating......27 ■ scanning.........40 Keys...........10 ON/OFF switch......15, 16 Killing off bacteria.......30...
  • Page 60 Keyword index Keyword index (cont.) Power supply blocked......42 Scan Power supply utility......42, 46 ■ Note..........40 Product features........6 ■ Note, warning and fault message...41 Product summary.........6 ■ Operating states......40 Programming unit......10, 12 ■ Solar thermal system......40 Pump ■ Temperatures.........40 ■ Cylinder heating......55 Scanning messages......41 ■...
  • Page 61 Keyword index Keyword index (cont.) Standard heating mode....7, 18, 54 Terminating Standard menu ■ DHW heating........33 ■ Instructions........12 ■ Economy mode.......25 ■ Menu structure........48 Terminating the holiday program..26 ■ Operation........11 Terminology........51 ■ Scanning information......40 Time ■ Standard menu.......48 ■ Factory setting........7 Standard room temperature...7, 18 Time phase Standard settings.......39...
  • Page 64 Contact your local contractor if you have any questions regarding the maintenance and repair of your system. You may, for example, find local contractors on the internet under www.viessmann.com. Viessmann Werke GmbH&Co KG Viessmann Limited D-35107 Allendorf Hortonwood 30, Telford...
