Moog Videolarm WM1500IR Installation And Operation Instructions

Ir illuminator adaptor bracket

Download this manual

W M 1 5 0 0 I R

IR Illuminator Adaptor Bracket

Installation and Operation Instructions for the following model:

WM1500IR

Wall mount bracket for IR Illuminators and ACH13 or ACH8

(IR Illuminator not included)

CONTENTS INCLUDED:

(1) Main bracket body

(1) Adjustable swivel head

(1) ¼-20 bolt (attached to swivel)

(1) IR Yoke

Before attempting to connect or operate this product, please read these instructions completely.

www.videolarm.com

81-IN5412

12-23-2011

Need help?

Do you have a question about the WM1500IR and is the answer not in the manual?

Page 1 © 2011, Moog Videolarm, Inc. All Rights Reserved W M 1 5 0 0 I R IR Illuminator Adaptor Bracket www.videolarm.com Installation and Operation Instructions for the following model: WM1500IR Wall mount bracket for IR Illuminators and ACH13 or ACH8...
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE COVER ( OR BACK).
Page 3: Terms And Conditions
If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Moog Videolarm. All claims for warranty service must be made within the warranty period.
Page 4 Power Box (Not included) Gasket (Included with PB24) Hardware (Included with PB24) Use the provided hardware and assemble Assemble the bracket to the Power Box and fasten the parts as shown in the above diagram. tightly. Check to see bracket is secure. •...
Page 5 Should a problem arise, rest assure that Moog Videolarm stands behind its products by offering impressive warranty plans: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on camera systems (SView, QView, Warriors), and InfraRed Illuminators.
