© 2011, Moog Videolarm, Inc. All Rights Reserved
P B 2 4 L 9 0 0
Rugged Wireless Power Box
Installation and Operation Instructions for the following model:
PB24L900
A rugged outdoor wireless box, with a 220/110Vac input and 24Vac
output for camera, fuse protected. With a wireless 900MHz transmitter
and matching receiver. Omni directional antenna.
Before attempting to connect or operate this product, please read these instructions completely.
www.videolarm.com
81-IN5381
01-23-2012
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Moog Videolarm PB24L900
Summary of Contents for Moog Videolarm PB24L900
- Page 1 © 2011, Moog Videolarm, Inc. All Rights Reserved P B 2 4 L 9 0 0 Rugged Wireless Power Box www.videolarm.com Installation and Operation Instructions for the following model: PB24L900 A rugged outdoor wireless box, with a 220/110Vac input and 24Vac output for camera, fuse protected.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE COVER ( OR BACK). - Page 3 If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Moog Videolarm. All claims for warranty service must be made within the warranty period.
- Page 4 Hardware is not provided for mounting this unit to the wall. PB24L900 is an 84vA Power Supply, designed for either 230Vac or 115vac input with 24Vac output. The unit includes a 900MHz wireless transmitter and matching receiver with an omni-directional antenna.
-
Page 5: Connecting Power
Connecting Power: 24VAC Power to Housing (Detail) H&B Ground Post H&B Camera Camera Incoming Ground 24VAC Power to Housing 24VAC Optional Output 120VAC Input GROUND 220-240VAC Input CONNECTING POWER Main On/Off Switch Input: Finishing the Installation: (120Vac or 240Vac) The Power Box provides 2 separate power output(s) at 24V. The Power Box is Once all wiring connections are completed;... -
Page 6: Wireless Setup
WIRELESS SETUP Name Function Color Once the dome is installed and power is connected to it, the wireless master Power Unit has power and has successfully booted. unit must be installed. Below is the basic setup for the master RF unit. Please RF Link The radio has successfully linked with its Green... - Page 7 INSTALLATION: should never try to point the ends of the antenna directly toward one another or directly away from one another. The 11dbi antennas are directional. They are designed so Once you have installed the antennas on the dome and master unit. You need to aim the radio wave will project directly out the front of the antenna.
- Page 8 INSTALLING MULTIPLE ANTENNAS: When installing more than one wireless unit in the same location, it is important to make sure that great care is taken to insure that the radio frequencies (channels) are properly spaced apart. For tower applications with two or three wireless master units in close proximity on the same pole, Videolarm recommends utilizing the manual channel mode;...
- Page 9 Up to 12 Radios – Advanced tower installations with many pan and tilt units will require careful planning and assessment by a qualified radio technician. Videolarm recommends utilizing the manual channel mode; antennae gain of 11dBi and mixed polarization between channels. It is recommended that antennae maintain a minimum of 4 ft of physical separation and are oriented with greater than 45°...
- Page 10 FAQ (Frequently Asked Questions) 7. What is the Fresnel zone? 1. What is the maximum number of Ethernet devices that can transmit across the link? The Fresnel Zone is the area around the visual line-of-sight that radio waves spread out into after they leave the antenna. Typically, 20% Fresnel Zone There is no limit to the number of client devices whose Ethernet traffic can be blockage introduces little signal loss to the link.
-
Page 11: Power Connection
Exploded View for Replacement Parts Replacement Parts List Part Number Description RP40HGPB1000 PB24 Housing Assembly RP40BRPBL24 900 MHz Bracket Assembly With Transformer and PCB RPPB241000 Grounding Stud and Terminal Connector RP70WPPH13 3 Position Incoming Power Plug Power Connection 120VAC Brown 120 VAC 220 VAC 115V 50/60hz... - Page 12 Exploded View for Replacement Parts Replacement Parts List Part Number RPVL2879 Wireless Base Bracket A RP70TRANS11 96VA 220/110 TO 24 CE/UL TRANSFORMER RPVL2885 Wireless box, bracket B RP76PCBPB01 POWER BOX CONNECTION PCG RP70WPPH08 3.81- 2 position Connector 1803578 RP70WPPH03 4 Position Connector 1803594 RP70CAPC02 12VDC POWER CONNECTOR - FEMALE RP70AW9XB...
-
Page 13: Mounting Template
Mounting Template 8.00 [ 203.2 ] 2.00 [ 50.8 ]... -
Page 14: Product Registration/Warranty
Should a problem arise, rest assure that Moog Videolarm stands behind its products by offering impressive warranty plans: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on camera systems (SView, QView, Warriors), and InfraRed Illuminators.
