-When going direct into a mixer/recorder, work with the input trim control on
the mixer and be sure not to overload its input.

SPEAKER SIMULATOR

The Speaker Simulator is engaged at all times. It shapes the sound to match the
particular cabinet of the amp type selected. It is specifically designed for a smooth,
even response as would be achieved by a multiple-miked cabinet, without peaks,
valleys, and notches associated with single miking.Therefore, it will not adversely
affect or interfere with the sound of your own guitar speaker cabinet.
When you disengage all 3 channels, the Speaker Simulator remains active, as does
the Master Output Section.The switching sequence then becomes Speaker Simulator
- Bypass, Speaker Simulator - Bypass, etc. This feature is useful to:
Record direct with a pre-amp, fuzz box or any other stomp
boxes in your collection that could use some warming up.
Warm up your favorite fuzz boxes in live performances, as well.
Use as a clean boost into the input of a tube amp.
Suggested Initial Set-Up: Turn all channels off.Turn the master Volume to maxi-
mum. Set Bass and Treble at 1 o'clock. Adjust to taste.

SIGNAL LEVEL TO INPUT

The TRI-O.D. is designed to accommodate instrument level signals to the Input,
such as the output of a guitar, the output of a pre-amp, the output of distortion
pedals, etc. Signal level to Input should be close to that of a standard electric guitar
(approx -10dB / 250mV). NOTE: Using hot pickups will increase the gain structure
of the TRI-O.D. For best results, use single coil pickups with Channel 1 (Tweed) and
double coil pickups with Channels 2 and 3 (California and British).
REMEMBER THIS WARNING:
DO NOT run the speaker output of any amp directly into the TRI-O.D.
Severe damage to the amp and/or the TRI-O.D. may result.
PLACEMENT ORDER OF OTHER EFFECTS
Place the following effects BEFORE the TRI-O.D.:
Wah-Wah, Pre-Amp, Compressor, Fuzz Box, Envelope Follower.
Place the following effects AFTER the TRI-O.D.:
Chorus, Delay, EQ, Pitch Shifter, Reverb.

POWER REQUIREMENTS

*
Utilizes standard 9V alkaline battery (not included).To install, simply
remove back plate. (NOTE: The Input activates battery.To conserve
energy, unplug when not in use.) Power Consumption: approx. 10mA.
*USE DC POWER SUPPLY ONLY!
the unit and void warranty. DC Power Supply Specifications:
-9V DC regulated or unregulated, 100mA minimum;
-2.1mm female plug, center negative (-).
WARNINGS:
* Attempting to repair unit is not recommended and may void warranty.
* Missing or altered serial numbers automatically void warranty. For your
own protection, be sure serial number labels on the unit's back plate and
exterior box are intact.
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE
REQUIRED.
Manufacturer warrants unit to be free from defects in materials
and workmanship for one (1) year from date of purchase.This warranty does not
include damage resulting from accident, misuse, abuse, alteration, or incorrect cur-
rent or voltage. If unit becomes defective within warranty period,Tech 21 will
elect to repair or replace it free of charge. After warranty expires,Tech 21 will
repair defective unit for a fee.
ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return
Authorization Number. Manufacturer will not accept packages without prior
authorization, pre-paid freight (UPS preferred) and proper insurance.
FOR PERSONAL ASSISTANCE & SERVICE:
Contact Tech 21, Inc., any weekday from 10:00 AM to 6:00 PM, EST.
MADE IN THE U.S.A.
T E C H 2 1 . N Y C
333 West 52nd Street, NY, New York 10019
212-315-1116 / Fax: 212-315-0825 / www.tech21nyc.com
Failure to do so may damage
